The soldering maximum capacity of the machine is between 1200 to 4000 pieces per hour.
This machine can solder mono-crystalline solar cells with sizes of 156×166mm, and it can accommodate different busbar configurations from 2 to 5 busbars.
The machine features a closed-loop control system for soldering temperature and power, allowing for smooth temperature adjustments and minimizing heat shock to reduce breakage rates.
The breakage rate during the soldering process is less than 0.2%, ensuring high efficiency and sustainability in production.
Yes, the cell spacing is adjustable between 1.5mm to 40mm, allowing flexibility based on production requirements.
The overall dimensions of the machine are 3875mm in length, 1320mm in width, and 2100mm in height.
The machine requires a 3-phase 380V, 50Hz power supply with reliable grounding.
The applicable air pressure for operation is between 0.6 to 0.8 MPa.
The power consumption of the machine is 12.5KW.
Yes, the machine can be integrated with an automatic layup machine to achieve the composing and locating of solar cell strings on tempered glass.
The machine utilizes a high-speed electric cylinder for cell classification handling and positioning, ensuring precise operation.
The deviation tolerance for ribbon and grid lines is less than ±0.2mm.
The machine can perform subsection soldering with infrared heating, allowing for high precision and reduced risk of damage to the solar cells.
Yes, the machine features an accurate and quantitative flux application system for optimal soldering results.
The machine can solder solar cells as small as 125mm x 125mm.
