Transformer Radiator Production Line ISO9001 CE 10 Years Warranty Production Radiator Machine
- Section : Machinery
- Category : Metal & Metallurgy Machinery
- SKU : 1600360029189
Transformer Radiator Production Line ISO9001 CE 10 Years Warranty Production Radiator Machine
The Transformer Radiator Production Line is a high-quality machine designed for making transformer oil tank fans. With a robust build and advanced technology, this production radiator machine offers exceptional performance and reliability. It comes with a 10-year warranty, ensuring you get long-lasting service and peace of mind.
Specifications
| Attribute | Details |
|---|---|
| Weight (KG) | 20000 |
| Brand Name | Darling Machinery |
| Application | Transformer Oil Tank Fan Making |
| Steel Plate Thickness | 1.0 ~ 1.5mm |
| Working Speed | 120m/min |
| Control System | PLC + Touch Screen |
| Panel Length | 500-4000mm |
| Panel Material | ST12, SPCC, DC01 Cold Rolled Steel, 1.0-1.2mm |
| Total Power | Approx 315KW |
| Total Line Dimension | 46.5m x 3.5m |
| Service Provided | Field Maintenance and Repair Service |
| Packaging Details | Fumigation-free wood box and waterproof film |
| Port of Dispatch | Qingdao Port |
| Selling Units | Single Item |
| Single Package Size | 2700X210X190 cm |
| Single Gross Weight | 30.000 KG |
| Supply Ability | 300 Sets per Year |
Key Features
- High production speed of 120m/min.
- Durable construction with steel plate thickness of 1.0-1.5mm.
- Easy-to-use PLC control system with a touch screen interface.
- Comprehensive service including installation and training.
- 10-year warranty for peace of mind.
Applications
- Manufacturing transformer oil tank fans.
- Production of various types of radiators.
- Used in industrial settings for radiator assembly.
- Suitable for companies looking to enhance their radiator production efficiency.
- Ideal for businesses requiring high-volume radiator manufacturing.
Product Info Gallery
- Shipping Timeframes: All orders are processed within 2-5 business days (excluding weekends and holidays). After your order has been processed, the estimated delivery time is before 03 Feb, 2026, depending on customs, Please note that due to high demand, some items may experience longer shipping times, which will be communicated at order confirmation email.
- Order Processing Time: Please allow 2-5 business days for us to process your order before it is shipped . Orders placed after 16:00 on Fridays, or during weekends and public holidays, will begin processing on the next business day. Processing times may be extended during peak seasons or sales events.
- Manufacturing Time: Some products needs manufacturing time, the manufacturing process will take approximately 10-30 business days depending on the product. This timeframe may vary depending on the complexity of the product and current demand. but this will be communicated with you during order confirmation.
- Returns and Exchanges: We offer a 30-day return policy for most items. If you are not completely satisfied with your purchase, you may return it within 30 days of receipt for a refund or exchange. Items must be unused, in their original packaging, and accompanied by proof of purchase. Return shipping costs are the responsibility of the customer, unless the item was damaged or defective upon arrival.
1. What is the Transformer Radiator Production Line used for?
It is designed for manufacturing transformer oil tank fans and various types of radiators in industrial production lines, enabling high-volume radiator assembly and fabrication.
2. What are the key technical specifications?
Key specs include: working speed 120 m/min; total power approx. 315 kW; total line dimension 46.5 m × 3.5 m; weight ~20,000 kg (gross package weight listed 30,000 kg); panel length 500–4000 mm; supported panel materials ST12, SPCC, DC01 cold-rolled steel; steel plate thickness typically 1.0–1.5 mm; control system PLC + touch screen.
3. What material thickness and sheet types does the line accept?
The line is built for cold-rolled steel such as ST12, SPCC and DC01. Recommended panel thicknesses are in the 1.0–1.5 mm range (panel material 1.0–1.2 mm is commonly used). If you need to run other materials or thicknesses, ask for an application review and possible tooling adjustments.
4. What is the production capacity and output speed?
Rated working speed is 120 m/min. Actual throughput depends on radiator size, cycle operations (cutting, forming, welding), and downstream processes — please provide your product dimensions for an estimated parts-per-hour figure.
5. What does the 10-year warranty cover?
A 10-year warranty is provided. Warranty coverage details (what components are included or excluded, wear parts, consumables, and service terms) are specified in the warranty agreement supplied with the machine. Contact sales for the full warranty document and any extended-service options.
6. Does the machine have quality and safety certifications?
Yes. The production line is supplied with ISO9001 quality management compliance and CE marking for conformity with relevant European safety, health and environmental protection requirements.
7. Is installation and operator training provided?
Yes. Comprehensive services including field installation, commissioning and operator training are provided. Ongoing field maintenance and repair service are also offered as part of after-sales support.
8. What are the electrical and power supply requirements?
Total installed power is approximately 315 kW. The machine requires an appropriate industrial three-phase power supply and proper electrical distribution. Exact voltage, frequency and wiring details will be provided in the electrical documentation and can be adapted to local standards on request.
9. What control system does the line use and is it user-friendly?
The line uses an industrial PLC with a touch-screen HMI for control. The interface is designed for simple operation; HMI language options and control logic can be customized to customer requirements.
10. How much factory floor space and site preparation are required?
The line footprint is about 46.5 m × 3.5 m. Additional clearance for material handling, operator access and safety zones is required. Site preparation typically includes a level foundation, suitable power supply, cranes/forklifts for installation and proper ventilation. Final civil and utility requirements will be provided during project planning.
11. How is the equipment packaged and shipped?
Equipment is packed in fumigation-free wooden boxes and wrapped with waterproof film. The listed port of dispatch is Qingdao Port. Single package size and gross weight details are provided on order documentation.
12. What is the typical lead time and annual supply capacity?
Supply capability is listed at up to 300 sets per year. Actual lead time depends on order quantity, customization and production schedule — contact sales for current delivery estimates for your order.
13. Are spare parts and consumables available?
Yes. Spare parts and consumables are available; the company provides field maintenance and repair service. We recommend stocking key wear parts locally; contact after-sales to arrange parts supply and recommended spare-parts lists.
14. Can the line be customized for different radiator designs or sizes?
Yes. Panel length range (500–4000 mm), tooling and process modules can be adapted for different radiator geometries. For custom requirements, provide drawings and production targets so we can propose configuration and tooling options.
15. What safety features are included and what operator protections are required?
The machine is CE-marked and supplied with standard safety features such as guards, emergency stop devices and interlocks. Proper operator PPE (gloves, eye protection, etc.), training and adherence to local occupational safety regulations are required. Additional safety measures can be added per customer request.
