Roadside 25cm-1meter Width Asphalt Paving Machine
- Section : Machinery
- Category : Construction Machinery
- SKU : 1601001624745
Roadside Asphalt Paving Machine
The Roadside Asphalt Paving Machine is a high-performance, versatile equipment designed for efficient paving of asphalt on roadsides, ideal for applications that require precise control and flexibility. This machine is built with advanced features that ensure a smooth, uniform asphalt surface with minimal operational effort.
Standard Configuration:
Hydraulic Bridge with Dual-Wheel Drive: Ensures stability and smooth operation, even on uneven surfaces.
Swiveling Steering Wheel: Allows for enhanced maneuverability, making it easier to navigate tight spaces.
Forward and Reverse Handle Control: Easy to operate in both directions for versatile usage.
Independent Control of Paving Thickness: Dual hydraulic cylinders on the left and right sides for precise control over paving thickness.
Selectable Paving Widths: Choose between four different paving widths to suit various project needs.
Engine Exhaust Heating Plate: Speeds up the asphalt curing process for better bonding and quality.
Detachable Hopper: Allows for easier unloading and maintenance.
Handle-Operated Brake: Provides added control and safety during operation.
Technical Specifications:
Maximum Operating Weight: 530 kg
Empty Weight: 260 kg
Dimensions:
Maximum Length: 2000 mm
Transport Dimensions (LxWxH): 1690x1000x1150 mm
Maximum Working Width: 1000 mm
Minimum Working Width: 250 mm
Chassis:
Front Drive Wheels: 2x Hydraulic drive wheels, diameter 400mm
Rear Steering Wheel: 1x Swivel wheel, diameter 260mm
Traction:
Maximum Working Speed: 28 m/min
Maximum Transport Speed: 3.2 km/h
Engine:
Model: HONDA GXV160
Emission Standard: EPA
Rated Power: 3.2 kW
Specifications: Air-cooled single-cylinder gasoline engine
Number of Cylinders: 1
Fuel Capacity: 4 L
This Roadside Asphalt Paving Machine is perfect for small-scale paving jobs, offering easy control, versatility in working widths, and precise paving thickness adjustments, making it an essential tool for efficient and high-quality roadside paving projects.
| Technical Specifications | Value |
| Weight | |
| Maximum Operating Weight | 530 kg |
| Empty Weight | 260 kg |
| Dimensions | |
| Maximum Length | 2000 mm |
| Transport Dimensions (LxWxH) | 1690x1000x1150 mm |
| Maximum Working Width | 1000 mm |
| Minimum Working Width | 250 mm |
| Chassis | |
| Front Drive Wheels | 2x Hydraulic drive wheels, diameter 400mm |
| Rear Steering Wheel | 1x Swivel wheel, diameter 260mm |
| Traction | |
| Maximum Working Speed | 28 m/min |
| Maximum Transport Speed | 3.2 Km/H |
| Engine | |
| Model | HONDA GXV160 |
| Emission Standard | EPA |
| Rated Power | 3.2 Kw |
| Specifications | Air-cooled single-cylinder gasoline engine |
| Number of Cylinders | 1 |
| Fuel Capacity | 4 L |
- Shipping Timeframes: All orders are processed within 2-5 business days (excluding weekends and holidays). After your order has been processed, the estimated delivery time is before 03 Feb, 2026, depending on customs, Please note that due to high demand, some items may experience longer shipping times, which will be communicated at order confirmation email.
- Order Processing Time: Please allow 2-5 business days for us to process your order before it is shipped . Orders placed after 16:00 on Fridays, or during weekends and public holidays, will begin processing on the next business day. Processing times may be extended during peak seasons or sales events.
- Manufacturing Time: Some products needs manufacturing time, the manufacturing process will take approximately 10-30 business days depending on the product. This timeframe may vary depending on the complexity of the product and current demand. but this will be communicated with you during order confirmation.
- Returns and Exchanges: We offer a 30-day return policy for most items. If you are not completely satisfied with your purchase, you may return it within 30 days of receipt for a refund or exchange. Items must be unused, in their original packaging, and accompanied by proof of purchase. Return shipping costs are the responsibility of the customer, unless the item was damaged or defective upon arrival.
1. What is the maximum paving width of the Roadside Asphalt Paving Machine?
The maximum paving width of the Roadside Asphalt Paving Machine is 1000 mm.
2. What is the minimum paving width that can be set on this machine?
The minimum paving width that can be set is 250 mm.
3. How heavy is the Roadside Asphalt Paving Machine?
The maximum operating weight is 530 kg, and the empty weight is 260 kg.
4. What type of engine does this paving machine use?
The machine is powered by a Honda GXV160 air-cooled single-cylinder gasoline engine.
5. What is the rated power of the engine?
The engine has a rated power of 3.2 kW.
6. Can the paving thickness be adjusted?
Yes, the paving thickness can be independently controlled using dual hydraulic cylinders on both sides.
7. What is the maximum working speed of the machine?
The maximum working speed of the Roadside Asphalt Paving Machine is 28 m/min.
8. Is the machine easy to operate?
Yes, it features a forward and reverse handle control for easy operation in both directions.
9. Does the machine have a detachable hopper?
Yes, it has a detachable hopper for easier unloading and maintenance.
10. What are the transport dimensions of the machine?
The transport dimensions are 1690 mm in length, 1000 mm in width, and 1150 mm in height.
11. How does the hydraulic bridge contribute to the operation?
The hydraulic bridge with dual-wheel drive ensures stability and smooth operation, even on uneven surfaces.
12. Can the paving machine be used in tight spaces?
Yes, the swiveling steering wheel allows for enhanced maneuverability, making it easier to navigate tight spaces.
13. What is the fuel capacity of the engine?
The fuel capacity of the engine is 4 liters.
14. What is the maximum transport speed of the machine?
The maximum transport speed is 3.2 km/h.
15. What are the benefits of the engine exhaust heating plate?
The engine exhaust heating plate speeds up the asphalt curing process for better bonding and quality.
