Railroad Steel Crane Railway Rail Guide Heavy Light Rail
- Section : Machinery
- Category : Engineering & Construction Machinery
- SKU : 10000018861337
| rail type | size （mm） | sectional area F (cm²) | (Kg/M) | ||||
| height A | bottom width B | head width C | web thickness D | weight per meter | |||
light rail | 8kg | 65 | 54 | 25 | 7 | 10.76 | 8.42 |
| 12kg | 69.85 | 69.85 | 38.1 | 7.54 | 11.54 | 12.2 | |
| 15kg | 79.37 | 79.37 | 42.86 | 8.33 | 19.33 | 15.2 | |
| 18kg | 90 | 80 | 40 | 10 | 23.07 | 18.06 | |
| 22kg | 93.66 | 93.66 | 50.8 | 10.72 | 28.39 | 22.3 | |
| 24kg | 107 | 92 | 51 | 10.9 | 31.24 | 24.46 | |
| 30kg | 107.95 | 107.95 | 60.33 | 12.3 | 38.32 | 30.1 | |
heavy rail | 38kg | 134 | 114 | 68 | 13 | 49.5 | 38.733 |
| 43kg | 140 | 114 | 70 | 14.5 | 57 | 44.653 | |
| 50kg | 152 | 132 | 70 | 15.5 | 65.8 | 51.514 | |
| 60kg | 176 | 150 | 73 | 16.5 | 77.45 | 60.64 | |
crane rail | QU70 | 120 | 120 | 70 | 28 | 67.3 | 52.8 |
| QU80 | 130 | 130 | 80 | 32 | 81.13 | 63.69 | |
| QU100 | 150 | 150 | 100 | 38 | 113.32 | 88.96 | |
| QU120 | 170 | 170 | 120 | 44 | 150.44 | 118.1 |
- Shipping Timeframes: All orders are processed within 2-5 business days (excluding weekends and holidays). After your order has been processed, the estimated delivery time is before 03 Feb, 2026, depending on customs, Please note that due to high demand, some items may experience longer shipping times, which will be communicated at order confirmation email.
- Order Processing Time: Please allow 2-5 business days for us to process your order before it is shipped . Orders placed after 16:00 on Fridays, or during weekends and public holidays, will begin processing on the next business day. Processing times may be extended during peak seasons or sales events.
- Manufacturing Time: Some products needs manufacturing time, the manufacturing process will take approximately 10-30 business days depending on the product. This timeframe may vary depending on the complexity of the product and current demand. but this will be communicated with you during order confirmation.
- Returns and Exchanges: We offer a 30-day return policy for most items. If you are not completely satisfied with your purchase, you may return it within 30 days of receipt for a refund or exchange. Items must be unused, in their original packaging, and accompanied by proof of purchase. Return shipping costs are the responsibility of the customer, unless the item was damaged or defective upon arrival.
1. What types of rails are available in the Railroad Steel Crane Railway Rail Guide?
The product features light rails and heavy rails, including sizes such as 8kg, 12kg, 15kg, 18kg, 22kg, 24kg, 30kg for light rails, and 38kg, 43kg, 50kg, 60kg for heavy rails, as well as crane rails like QU701, QU801, QU100, and QU120.
2. What are the dimensions of the light rail types?
The dimensions for light rail types vary: for example, the 8kg rail has a height of 65mm, bottom width of 42mm, head width of 57mm, and a web thickness of 10.7mm.
3. What is the weight capacity of the heavy rail?
The heavy rail types range in weight capacities, with options available from 38kg to 60kg, designed for heavy-duty applications.
4. What is the sectional area of the 15kg light rail?
The sectional area of the 15kg light rail is 42.8 cm².
5. How much does the 24kg light rail weigh per meter?
The 24kg light rail weighs approximately 30.1 kg per meter.
6. What is the web thickness of the QU100 crane rail?
The QU100 crane rail has a web thickness of 13.3mm.
7. Are these rails suitable for outdoor use?
Yes, the Railroad Steel Crane Railway Rails are designed for durability and can be used in outdoor environments.
8. Can I use these rails for a DIY project?
Yes, these rails can be used for various DIY projects, but it's important to ensure they meet the specific requirements of your project.
9. What is the height of the 60kg heavy rail?
The height of the 60kg heavy rail is 176mm.
10. Do you provide installation instructions with the rails?
Installation instructions are typically not included, but we recommend consulting a professional for proper installation.
11. What is the difference between light rail and heavy rail?
Light rail is designed for lighter loads and speeds, while heavy rail is built for more demanding applications with higher weight capacities and durability.
12. Is there a warranty for the Railroad Steel Crane Railway Rails?
Warranty details can vary by seller; please check with your supplier for specific warranty information.
13. What is the weight per meter for the QU120 crane rail?
The QU120 crane rail weighs approximately 118.1 kg per meter.
14. Can I mix different types of rails in my installation?
Mixing different types of rails is not recommended as each type has specific weight and load specifications that must be adhered to.
