Product Description
PCR Thermal Cycler TC1000-G
• Reliable heating/cooling elements and precise temperature control
• Unique design of block ensur es the temperature uniformity and repeatable results
• 7 inch Large color touch panel screen for easy programming with user friendly software
• Large user program storage
• High performance DSP and temperature control
• Fast heating and cooling rate
| Specifications | TC1000-G |
| Sample Capacity | 96X0.2mL PCR tube, 8X12 PCR plate or 96 well plate |
| Heating Temperature Range | 4-105℃ |
| Lid Temperature Range | 30-110℃ |
| Temperature Display Accuracy | ±0.1℃ |
| Temperature Control Accuracy [at 55℃] | ±0.3℃ |
| Temperature uniformity[at 55℃] | <0.3℃ |
| Max. Heating/Cooling Rate | 3℃Sec |
| Gradient Temperature Setting Range | 30-99℃ |
| Gradient Range | 1-42℃ |
| Adapter block material | aluminum |
| Display | 7” LCD 800x480 |
| Input | Touch panel |
| User defined file system | Max. 30 segments 99 cycles max. 16 folder and 16 files each folder |
| Power off protection | Yes |
| Power Supply | 100-120V/200-240V,50/60Hz |
| Dimension [D×W×H] ( without the heating block ) | 280x370x250 mm |
| Weight | 11kg |
- Shipping Timeframes: All orders are processed within 2-5 business days (excluding weekends and holidays). After your order has been processed, the estimated delivery time is before 03 Feb, 2026, depending on customs, Please note that due to high demand, some items may experience longer shipping times, which will be communicated at order confirmation email.
- Order Processing Time: Please allow 2-5 business days for us to process your order before it is shipped . Orders placed after 16:00 on Fridays, or during weekends and public holidays, will begin processing on the next business day. Processing times may be extended during peak seasons or sales events.
- Manufacturing Time: Some products needs manufacturing time, the manufacturing process will take approximately 10-30 business days depending on the product. This timeframe may vary depending on the complexity of the product and current demand. but this will be communicated with you during order confirmation.
- Returns and Exchanges: We offer a 30-day return policy for most items. If you are not completely satisfied with your purchase, you may return it within 30 days of receipt for a refund or exchange. Items must be unused, in their original packaging, and accompanied by proof of purchase. Return shipping costs are the responsibility of the customer, unless the item was damaged or defective upon arrival.
1. What is the sample capacity of the TC1000-G PCR Thermal Cycler?
The TC1000-G can accommodate 96 x 0.2mL PCR tubes, an 8 x 12 PCR plate, or a 96 well plate.
2. What is the temperature range for heating and lid temperature?
The heating temperature range is 4-105℃, while the lid temperature range is 30-110℃.
3. How accurate is the temperature display and control?
The temperature display accuracy is ±0.1℃, and the temperature control accuracy at 55℃ is ±0.3℃.
4. What is the maximum heating and cooling rate of the machine?
The maximum heating and cooling rate is 3℃ per second.
5. Does the TC1000-G have a gradient temperature setting feature?
Yes, the gradient temperature setting range is from 30-99℃ with a gradient range of 1-42℃.
6. What type of display does the TC1000-G have?
It features a 7-inch LCD touch panel display with a resolution of 800x480.
7. Is the software user-friendly?
Yes, the TC1000-G comes with user-friendly software that allows for easy programming.
8. How many user-defined programs can be stored?
The TC1000-G allows for a large user program storage, accommodating up to 30 segments and 99 cycles, with a maximum of 16 folders and 16 files in each folder.
9. What is the power supply requirement for the TC1000-G?
The power supply requirement is 100-120V/200-240V at 50/60Hz.
10. What are the dimensions and weight of the TC1000-G?
The dimensions are 280mm (D) x 370mm (W) x 250mm (H) without the heating block, and it weighs 11 kg.
11. Does the TC1000-G have a power-off protection feature?
Yes, it is equipped with power-off protection to ensure data safety.
12. Can I use this machine for real-time PCR testing?
Yes, the TC1000-G is designed for fast testing and is suitable for real-time PCR applications.
13. What materials are used for the adapter block?
The adapter block is made of aluminum, ensuring optimal heat conduction.
14. Is there customer support available for the TC1000-G?
Yes, customer support is typically available through the manufacturer or retailer for any inquiries or issues.
15. Can I program the TC1000-G for specific testing protocols?
Yes, you can create and save custom programs tailored to your specific testing protocols.
