Industrial Grade High Precision Table Type Automatic 3 Axis Plate Tube CNC Laser Cutting Machine for Sheet Metal
- Section : Machinery
- Category : Machine Tool Equipment
- SKU : 1601405262350
Industrial Grade High Precision Table Type Automatic 3 Axis Plate Tube CNC Laser Cutting Machine for Sheet Metal
The Industrial Grade High Precision Table Type Automatic 3 Axis Plate Tube CNC Laser Cutting Machine is a powerful tool designed for cutting sheet metal with high accuracy. It uses advanced fiber laser technology to ensure clean and precise cuts. This machine is perfect for industries that require precision metal working. With a strong structure and user-friendly features, it is suitable for both professionals and beginners.
Specifications
| Attribute | Details |
|---|---|
| Voltage | 380V |
| Rated Power | 3.0KW |
| Weight | 3500 kg |
| Dimensions (L*W*H) | 4.4 m * 2.28 m * 1.85 m |
| Laser Power | 3000W |
| Process Area | 3000 mm x 1500 mm |
| Moving Speed | 200 m/min |
Key Features
- Automatic operation for easy use.
- High precision cutting for detailed work.
- Robust core components for long-lasting performance.
- Heavy-duty design with a weight of 3500 kg.
- Fast moving speed up to 200 m/min.
- Customizable color options available.
Applications
- Sheet metal fabrication.
- Automotive parts manufacturing.
- Aerospace component production.
- Custom metal artwork.
- Signage and display creation.
- Electrical enclosure fabrication.
Product Info Gallery
- Shipping Timeframes: All orders are processed within 2-5 business days (excluding weekends and holidays). After your order has been processed, the estimated delivery time is before 03 Feb, 2026, depending on customs, Please note that due to high demand, some items may experience longer shipping times, which will be communicated at order confirmation email.
- Order Processing Time: Please allow 2-5 business days for us to process your order before it is shipped . Orders placed after 16:00 on Fridays, or during weekends and public holidays, will begin processing on the next business day. Processing times may be extended during peak seasons or sales events.
- Manufacturing Time: Some products needs manufacturing time, the manufacturing process will take approximately 10-30 business days depending on the product. This timeframe may vary depending on the complexity of the product and current demand. but this will be communicated with you during order confirmation.
- Returns and Exchanges: We offer a 30-day return policy for most items. If you are not completely satisfied with your purchase, you may return it within 30 days of receipt for a refund or exchange. Items must be unused, in their original packaging, and accompanied by proof of purchase. Return shipping costs are the responsibility of the customer, unless the item was damaged or defective upon arrival.
1. What is the Industrial Grade High Precision Table Type Automatic 3 Axis Plate Tube CNC Laser Cutting Machine?
It is a heavy-duty table-type CNC fiber laser cutting machine designed for high-precision cutting of sheet metal and tubes. It combines a 3-axis cutting system, automatic operation features, and robust mechanical components for industrial fabrication, automotive, aerospace, signage and other metalworking applications.
2. What type of laser does the machine use and what is the laser power?
The machine uses an advanced fiber laser source with a nominal laser power of 3000 W (3 kW), providing clean, efficient cuts across a range of conductive metals.
3. What are the main electrical and machine power specifications?
The machine requires a 380 V three-phase power supply and has a rated power of 3.0 kW (in addition to the laser source rating). Additional utilities such as cooling water, compressed air and assist gases are typically required depending on the cutting application.
4. What is the working (process) area and overall machine size?
The specified process area is 3000 mm x 1500 mm. Overall machine dimensions are approximately 4.4 m (L) x 2.28 m (W) x 1.85 m (H), and the machine weight is about 3500 kg.
5. What materials can this machine cut?
Common materials include mild (carbon) steel, stainless steel, aluminum, copper and brass. Cutting performance depends on material type, thickness, surface condition and assist gas selection.
6. What cutting thicknesses can I expect with a 3 kW fiber laser?
Typical achievable thicknesses (approximate and application-dependent): mild/carbon steel up to ~20 mm (with oxygen assist), stainless steel and aluminum typically up to ~8–12 mm. Actual capability depends on material, gas, nozzle, cutting parameters and part quality — verify with the supplier for certified capacities.
7. What cutting speed and accuracy does the machine offer?
The machine has a maximum moving speed up to 200 m/min. Typical high-precision cutting tolerances for industrial fiber laser cutting machines are on the order of ±0.03–±0.05 mm positioning accuracy with similar repeatability, though exact precision depends on material, part size, fixturing and cutting parameters.
8. Can the machine cut both plates (sheets) and tubes?
Yes — the model is described as plate and tube capable. Tube cutting requires the appropriate rotary fixtures/chucks and tooling configuration; confirm with the supplier which tube diameters, lengths and profiles are supported and whether the rotary attachment is included or optional.
9. What software and file formats are supported?
The machine is compatible with standard CNC laser cutting controllers and commonly used CAD/CAM or nesting software. Typical supported file formats include DXF, DWG, PLT and other vector formats. Confirm the exact control software and features (nesting, parametric cutting, material libraries) with the vendor.
10. What accessories and auxiliary systems are required or recommended?
Recommended accessories include a chiller or industrial water cooler for the laser source, fume extraction or filtration system, high-pressure gas supply (oxygen/nitrogen) for cutting, air compressor, protective laser safety shielding and a material loading/unloading system or automatic pallet if required.
11. What routine maintenance does the machine need?
Typical maintenance includes cleaning and inspecting focusing optics and protective windows, checking and replacing nozzles and consumables, lubrication of guide rails and bearings, verifying alignment and belt/drive tension, draining/maintaining the chiller and filters, and keeping the work area and exhaust clean. Follow the supplier's maintenance schedule for intervals and procedures.
12. What safety features should I expect and what precautions are required?
Expect emergency stop buttons, safety interlocks on access panels, proper grounding, and recommendations for laser safety eyewear and ventilation. A certified fume extraction system is essential for operator safety. Ensure the machine is installed in a compliant workspace and operators follow local laser safety regulations.
13. Is installation, commissioning and operator training provided?
Many suppliers offer on-site installation, commissioning and operator training as part of the purchase or as an add-on service. Remote support and initial setup assistance are also commonly available. Confirm the availability, scope and any associated costs with your vendor before purchase.
14. What warranty and after-sales support are available?
Warranty terms and after-sales service vary by supplier. Typical offerings include limited warranty on the machine and laser source, spare parts supply, technical support and service contracts. Ask the vendor for specific warranty duration, what is covered, spare-part lead times and available service plans.
15. Can the machine be customized (color, options, attachments)?
Yes — the product notes customizable color options and manufacturers commonly offer optional attachments such as automatic loaders/unloaders, rotary tube fixtures, different nozzles, higher-precision heads, upgraded controllers or remote monitoring. Discuss required custom options with the supplier to receive a tailored quote.
