Home Beer Making Machine Turnkey Project:
- Section : Machinery
- Category : Food & Beverage Machinery
- SKU : 1600883664338
PRODUCT DESCRIPTION
Brewhouse
Brewhouse
Vessels:
Regular: MLT+BKW+HLT.
Mash/Brew Kettle +Lauter & Whirlpool Tank.
Others: Mash, Lauter, Brew, Whirlpool, HLT, CLT
Heating Method:Steam Heating/Electric Heating/ Direct fire/Baine Marie
Specifications:
-With 30% Total Volume
-Dome top and cone bottom; bottom cone 160 degree
-Interior Shell: SUS304, T 3.0mm
-Exterior Shell: SUS304, T 2.0mm
-Insulation: PU/Rockwool T 100mm
-100% TIG welding with pure argon gas shield
-Interior Finish: 0.4~0.6μm/ Mirror Polishing
-Top mounted manhole
-360° CIP spraying ball
-Thermowell with high accuracy temperature sensor: PT100
-MLT with agitator with motor reducer, CE/UL Listed
-MLT with side manhole for spent grains
(For High Plato, the Lauter tank can be customized)
-MLT with easy-clean and detachable Sparging arm
-MLT with easy-clean and detachable False bottom
-BKW with tangential inlet for whirlpool function
Plate Heat Exchanger (China Top Brand)
-2 stages for Glycol water and City water
-SUS 304 Plates and frame
Wort and HLT Pumps:-CE/UL Listed
Oxygenator
Brewhouse pipelines and Valves
SUS 304 Working Platform
Optional:
-Grist Case;-Wort Buffer Tank;-Platform with Sink;-Flow meter;-Pneumatic Valves;-Others
2-Vessels Combined Brewhouse 3-Vessels Brewhouse
BEER FERMENTATION TANK
Beer Fermenting Vessel/Brites
-Total capacity: with 25% headspace
-Dome top and cone bottom, bottom cone, (60 degree for BFV)
-Interior Shell: SUS304, T 3.0mm;
-Exterior Shell: SUS304, T 2.0mm;
-Insulation: PU, T100mm
-100% TIG welding with pure argon gas shield
-Interior Finish: to 0.4~0.6μm/ Mirror polishing
-Cooling Jacket: both on cone and cylinder parts, T 1.5mm
-Top mounted manhole/Side manhole
-Relief/vacuum valve
-Dry hop port
-Thermometer
-Sample valve
-Bung apparatus with pressure gauge
-Test Pressure: 0.3Mpa, Working pressure: 0.15-0.2Mpa.
-Rotating racking arm on cone with butterfly valve
-Drainage with butterfly valve
-CIP arm with 360° spraying ball
-Thermowell with high accuracy temperature sensor: PT100
Optional:
Level Tube
CO2 Carbonation Stone
Copper Shell
Pressurized Hop drop feeder
Other requirements
Dimension design
- Shipping Timeframes: All orders are processed within 2-5 business days (excluding weekends and holidays). After your order has been processed, the estimated delivery time is before 03 Feb, 2026, depending on customs, Please note that due to high demand, some items may experience longer shipping times, which will be communicated at order confirmation email.
- Order Processing Time: Please allow 2-5 business days for us to process your order before it is shipped . Orders placed after 16:00 on Fridays, or during weekends and public holidays, will begin processing on the next business day. Processing times may be extended during peak seasons or sales events.
- Manufacturing Time: Some products needs manufacturing time, the manufacturing process will take approximately 10-30 business days depending on the product. This timeframe may vary depending on the complexity of the product and current demand. but this will be communicated with you during order confirmation.
- Returns and Exchanges: We offer a 30-day return policy for most items. If you are not completely satisfied with your purchase, you may return it within 30 days of receipt for a refund or exchange. Items must be unused, in their original packaging, and accompanied by proof of purchase. Return shipping costs are the responsibility of the customer, unless the item was damaged or defective upon arrival.
1. What is included in the Home Beer Making Machine Turnkey Project?
The project includes a complete brewhouse setup with vessels for mashing, boiling, lautering, and fermenting, along with pumps, pipelines, and optional equipment such as grist cases and wort buffer tanks.
2. What materials are used in the construction of the brewing vessels?
The brewing vessels are made from SUS304 stainless steel, featuring different thicknesses for interior and exterior shells, and are designed for durability and corrosion resistance.
3. How does the heating system work in the brewhouse?
The heating system can utilize steam heating, electric heating, direct fire, or Baine Marie methods, allowing flexibility based on your preferences and requirements.
4. What is the capacity of the fermentation tank?
The fermentation tank has a total capacity designed to allow for 25% headspace to accommodate foaming during fermentation.
5. Is the Home Beer Making Machine suitable for beginners?
Yes, the Home Beer Making Machine is designed to be user-friendly, making it suitable for both beginners and experienced brewers.
6. What is the significance of the 360° CIP spraying ball?
The 360° CIP (Clean In Place) spraying ball ensures thorough cleaning of the interior surfaces of the vessels, which is essential for maintaining hygiene and preventing contamination.
7. Can I customize the brewhouse setup?
Yes, the brewhouse setup can be customized based on your brewing needs, including options for different vessel configurations and additional equipment.
8. What kind of insulation is used in the brewing vessels?
The brewing vessels are insulated with either PU or Rockwool material, measuring 100mm thick to help maintain temperature during the brewing process.
9. Are the components CE/UL listed?
Yes, the major components such as the pumps and agitators are CE and UL listed, ensuring they meet international safety and quality standards.
10. What is the purpose of the sample valve on the fermentation tank?
The sample valve allows brewers to take samples of the beer during fermentation for testing and monitoring without having to open the tank.
11. How does the oxygenation process work in this system?
The included oxygenator facilitates controlled oxygen input into the wort, which is essential for yeast health and fermentation efficiency.
12. What is the cleaning process for the brewhouse?
The brewhouse features a CIP system that allows for easy cleaning of the vessels and piping without disassembly, ensuring a quick and effective hygiene routine.
13. Can additional features be added to the brewhouse?
Yes, optional features like flow meters, pneumatic valves, and additional tanks can be added to enhance the brewing setup.
14. What is the importance of the thermowell with a PT100 sensor?
The thermowell with a PT100 sensor provides accurate temperature readings, which are critical for controlling the brewing and fermentation processes.
15. What types of beer can I brew with this machine?
You can brew a wide variety of beers, including ales, lagers, stouts, and more, depending on your recipe and brewing techniques.
