The maximum loading capacity of the High Precision Steel Ball Lapping Machine is 500 kg.
This machine can handle steel balls ranging from 12 mm to 70 mm in diameter.
The machine requires a power supply of 5.5 kW.
The dimensions of the machine are 3550 mm in length, 2135 mm in width, and 1535 mm in height.
Yes, the machine is designed for international use and comes with an overseas service center for support.
The maximum working pressure of the High Precision Steel Ball Lapping Machine is 80 kN.
Yes, it features a user-friendly touch screen control panel for easy operation.
This machine is suitable for the metalworking and metallurgy industries, particularly for manufacturing bearing steel balls.
The weight of the High Precision Steel Ball Lapping Machine is 3250 kg.
The machine comes equipped with a famous brand PLC for reliable operation.
The frequency error range for the machine is between 0.99 to 1.01 rate frequency.
The required foundation depth for the machine should be no less than 400 mm.
Yes, it is suitable for R&D labs focusing on metal ball applications.
The machine combines advanced technology and a user-friendly interface to ensure high precision during the lapping processes.
The levelness specification for the installation of the machine is 0.04/1000.
