High Precision 145T Non-ferrous Cold Chamber Die Casting Machine
- Section : Machinery
- Category : Metal & Metallurgy Machinery
- SKU : 1600585817106
High Precision 145T Non-ferrous Cold Chamber Die Casting Machine
The High Precision 145T Non-ferrous Cold Chamber Die Casting Machine is designed for efficiency and performance. This machine is perfect for creating high-quality aluminum castings. With its robust features, it ensures long-lasting durability and reliability in various applications.
Specifications
| Attribute | Details |
|---|---|
| Machine Type | Cold Chamber Die Casting Machine |
| Power (kW) | 11 |
| Weight (kg) | 6500 |
| Max Thickness of Die Block (mm) | 500 |
| Min Thickness of Die Block (mm) | 250 |
| Injection Force (kN) | 108 |
| Injection Stroke (mm) | 85 |
| Dimension (L*W*H) | 5680 x 1610 x 2854 |
| Shot Weight (Aluminum) | 0.7 - 1.6 kgs |
| Casting Area | 82 - 186 cm² |
| Max Casting Area under 40Mpa | 362 cm² |
| Shot Position Below Center Line | -100 mm |
| Platen Size | 650 x 650 mm |
| Main Pump Driving Motor | 11 kW |
| Oil Tank Capacity | 480 L |
| Hydraulic Working Pressure | 14 Mpa |
Key Features
- Long service life for reliable performance.
- High precision for excellent casting quality.
- Video outgoing inspection for quality assurance.
- Comprehensive machinery test report provided.
Applications
- Automotive parts manufacturing.
- Electrical components casting.
- Industrial machinery parts production.
- Aerospace component fabrication.
The High Precision 145T Non-ferrous Cold Chamber Die Casting Machine is your ideal partner for achieving high-quality die casting results. Upgrade your production line with this advanced machine today!
Product Info Gallery
- Shipping Timeframes: All orders are processed within 2-5 business days (excluding weekends and holidays). After your order has been processed, the estimated delivery time is before 04 Feb, 2026, depending on customs, Please note that due to high demand, some items may experience longer shipping times, which will be communicated at order confirmation email.
- Order Processing Time: Please allow 2-5 business days for us to process your order before it is shipped . Orders placed after 16:00 on Fridays, or during weekends and public holidays, will begin processing on the next business day. Processing times may be extended during peak seasons or sales events.
- Manufacturing Time: Some products needs manufacturing time, the manufacturing process will take approximately 10-30 business days depending on the product. This timeframe may vary depending on the complexity of the product and current demand. but this will be communicated with you during order confirmation.
- Returns and Exchanges: We offer a 30-day return policy for most items. If you are not completely satisfied with your purchase, you may return it within 30 days of receipt for a refund or exchange. Items must be unused, in their original packaging, and accompanied by proof of purchase. Return shipping costs are the responsibility of the customer, unless the item was damaged or defective upon arrival.
1. What types of materials can be used with the High Precision 145T Non-ferrous Cold Chamber Die Casting Machine?
This machine is specifically designed for non-ferrous metals, primarily aluminum, making it ideal for high-quality aluminum castings.
2. What is the maximum injection force of this die casting machine?
The High Precision 145T Non-ferrous Cold Chamber Die Casting Machine has a maximum injection force of 108 kN.
3. What is the weight of the machine?
The machine weighs approximately 6500 kg.
4. What are the dimensions of the machine?
The dimensions of the machine are 5680 mm in length, 1610 mm in width, and 2854 mm in height.
5. What is the oil tank capacity of this machine?
The oil tank capacity of the High Precision 145T Non-ferrous Cold Chamber Die Casting Machine is 480 liters.
6. What is the hydraulic working pressure of the machine?
The hydraulic working pressure is 14 Mpa.
7. What is the shot weight range for aluminum?
The shot weight for aluminum ranges from 0.7 to 1.6 kgs.
8. Can this machine be used for aerospace component fabrication?
Yes, the High Precision 145T Non-ferrous Cold Chamber Die Casting Machine is suitable for aerospace component fabrication, among other applications.
9. What quality assurance measures are in place for this machine?
The machine undergoes video outgoing inspection and comes with a comprehensive machinery test report to ensure quality assurance.
10. What is the maximum and minimum thickness of the die block that can be used?
The maximum thickness of the die block is 500 mm, while the minimum thickness is 250 mm.
11. What is the injection stroke length of the machine?
The injection stroke length of the High Precision 145T Non-ferrous Cold Chamber Die Casting Machine is 85 mm.
12. Is this machine suitable for automotive parts manufacturing?
Yes, this machine is well-suited for automotive parts manufacturing, as well as other industrial applications.
13. What is the casting area range for this machine?
The casting area for this machine ranges from 82 cm² to 186 cm², with a maximum casting area under 40 Mpa of 362 cm².
14. What is the main pump driving motor power?
The main pump driving motor has a power rating of 11 kW.
15. How does this machine ensure long-lasting durability and reliability?
The High Precision 145T Non-ferrous Cold Chamber Die Casting Machine is built with robust features and materials that enhance its durability and reliability in various applications.
