Heavy Duty 1212 Wood 3 Axis 3d CNC Router 2040 Engraving and Milling Machines Cutter Woodworking CNC for Router
- Section : Machinery
- Category : Woodworking Machinery
- SKU : 1601210122252
Heavy Duty 1212 Wood 3 Axis 3D CNC Router 2040 Engraving and Milling Machines
The Heavy Duty 1212 Wood 3 Axis 3D CNC Router is a powerful tool for woodworking and milling. It is designed for precision and durability, making it perfect for both professional and hobbyist use. This machine can handle various materials, including wood, MDF, acrylic, and soft metals. With its advanced features and high performance, it is an excellent choice for all your engraving and milling needs.
Specifications
| Attribute | Details |
|---|---|
| Working Table Size (mm) | 2000 × 4000 |
| Machine Type | CNC Router |
| Number of Axes | 3 |
| Number of Spindles | Single |
| CNC or Not | CNC |
| Voltage | 220V/380V |
| Power (kW) | 3 |
| Weight (kg) | 1200 |
| Range of Spindle Speed (RPM) | 1 - 24000 |
| Positioning Accuracy (mm) | 0.03 |
| Travel (X Axis) (mm) | 2000 |
| Travel (Y Axis) (mm) | 4000 |
| Repeatability (X/Y/Z) (mm) | 0.03 |
| Spindle Motor Power (kW) | 3 - 6 (optional) |
| Dimensions (L*W*H) | 2150*3000*1800 mm |
| Core Components | Motor, Control System (DSP, Mach 3/4, Nc-studio options) |
| Motor | Stepper motor and driver |
| Collet | ER25 |
| Accuracy | ±0.03 mm |
| Key Selling Points | High precision, energy saving, heavy duty |
Key Features
- Heavy duty design for long-lasting use.
- High precision with an accuracy of ±0.03 mm.
- Fast spindle speed up to 24000 RPM.
- Large working table for big projects.
- Eco-friendly machinery with energy-saving features.
- Easy-to-use control system options available.
Applications
- Engraving intricate designs on wood and acrylic.
Product Info Gallery
- Shipping Timeframes: All orders are processed within 2-5 business days (excluding weekends and holidays). After your order has been processed, the estimated delivery time is before 03 Feb, 2026, depending on customs, Please note that due to high demand, some items may experience longer shipping times, which will be communicated at order confirmation email.
- Order Processing Time: Please allow 2-5 business days for us to process your order before it is shipped . Orders placed after 16:00 on Fridays, or during weekends and public holidays, will begin processing on the next business day. Processing times may be extended during peak seasons or sales events.
- Manufacturing Time: Some products needs manufacturing time, the manufacturing process will take approximately 10-30 business days depending on the product. This timeframe may vary depending on the complexity of the product and current demand. but this will be communicated with you during order confirmation.
- Returns and Exchanges: We offer a 30-day return policy for most items. If you are not completely satisfied with your purchase, you may return it within 30 days of receipt for a refund or exchange. Items must be unused, in their original packaging, and accompanied by proof of purchase. Return shipping costs are the responsibility of the customer, unless the item was damaged or defective upon arrival.
1. What materials can the Heavy Duty 1212 Wood CNC Router handle?
The Heavy Duty 1212 Wood CNC Router can handle various materials including wood, MDF, acrylic, and soft metals.
2. What is the maximum spindle speed of this CNC router?
The maximum spindle speed of the Heavy Duty 1212 Wood CNC Router is up to 24000 RPM.
3. What is the accuracy of the CNC router?
This CNC router has a positioning accuracy of ±0.03 mm.
4. What are the dimensions of the machine?
The dimensions of the Heavy Duty 1212 Wood CNC Router are 2150 mm (L) x 3000 mm (W) x 1800 mm (H).
5. Does the router come with a control system?
Yes, the machine is equipped with a control system that offers options such as DSP, Mach 3/4, and Nc-studio.
6. What is the weight of the CNC router?
The Heavy Duty 1212 Wood CNC Router weighs 1200 kg.
7. Is this machine suitable for beginners?
Yes, the Heavy Duty 1212 Wood CNC Router is designed with an easy-to-use control system, making it suitable for both beginners and professionals.
8. What is the power requirement for this router?
The Heavy Duty 1212 Wood CNC Router requires a voltage of 220V/380V and has an optional spindle motor power ranging from 3 to 6 kW.
9. What is the travel range for the X and Y axes?
The travel range is 2000 mm for the X axis and 4000 mm for the Y axis.
10. Can this machine be used for engraving?
Yes, the Heavy Duty 1212 Wood CNC Router is ideal for engraving intricate designs on wood and acrylic.
11. What makes this CNC router energy efficient?
The Heavy Duty 1212 Wood CNC Router features eco-friendly machinery and energy-saving functionalities.
12. What type of motor is used in this CNC router?
The machine uses a stepper motor and driver for precise control.
13. Does the router come with a warranty?
Please check with the retailer for specific warranty information regarding the Heavy Duty 1212 Wood CNC Router.
14. What is the repeatability of the machine?
The repeatability of the Heavy Duty 1212 Wood CNC Router is ±0.03 mm for the X, Y, and Z axes.
15. Is assembly required for the CNC router?
Some assembly may be required upon delivery. Please refer to the user manual for detailed instructions.
