DAS Mesin Bubut Precision Slant Bed CNC Turning Lathe Machine Mazak Automatic Horizontal Cnc Lathe Machine
- Section : Machinery
- Category : Lathe
- SKU : 1600213130572
Product Description
CNC Lathe Video Request Click This LinkBenchtop cnc lathe
Products Description
The machine is suitable to process all kinds of small and middle-sized shaft and plate work piece, and could also turn various threads, circle arc, circular cone, inside and outside surface of revolved body. This machine is widely used in sanitary, valve, electrical appliance, instrument, automobile, motorcycle, bearings and so on.
1. Super rigidity
The body structure is one piece, with a solid base and a downfeed centre, 45° saddle design for good vibration damping and reduced deformation, providing a very stable base for the head and turret, 45° sloping bed structure for easy loading and unloading of steel and smoother chip removal.
2. Modern and popular control components
The DAS 46 series is available with the optional FAUNC 0iTF control package and Siemens 828D control package, 8.4' display, 10.4' display, additional interfaces, etc.
3. Superb price/performance ratioThe 46C series of German origin has the best components, such as SAUTER turret and NSK bearings, which guarantee the high precision performance of the 46C series. At the same time we offer competitive prices, making the 46C series superbly cost effective.
4. User-friendly design
Minimal space occupation, but mostly in line with the actual working area, full protective cover, humanized aesthetic design, stainless steel telescope cover, providing a safe and clean working environment and more durable.
5. Rich choiceElectric turret, servo turret, power turret, upgraded spindle power, upgraded spindle torque, upgraded cylinder and chuck inner diameter, drawer type cooling tank, tool probe, oil mist remover, etc. for customers to choose from.
6. High efficiency assembly line operation (optional)Thanks to the advanced truss drive, multiple machines can be combined together to complete a task, greatly reducing the drive time between each process and increasing efficiency.
| Name | CNC36A | CNC46A |
| The maximum diameter of rotation (mm) | 310 | 310 |
| Max.cutting length (mm) | 100/200 | 100/200 |
| With chuck size | 5 Inch | 6 Inch |
| Spindle speed (r/min) | 45-4500 | 45-4500 |
| Spindle power (KW) | 3.7 | 5.5(Optional) |
| Spindle bore (mm) | Φ46 | Φ56 |
| Auto feeding max.diameter (mm) | Φ35 | Φ45 |
| Min.resolution (mm) | 0.001 | 0.001 |
| X/Z Axis stroke (mm) | 340/250 | 340/250 |
| X/Z axis fast moving speed (m/min) | 18 | 18 |
| X/Z axis Repetitive positioning accuracy (mm) | 0.003/0.003 | 0.003/0.003 |
| Cutting feed rate (mm/min) | 0-5000 | 0-5000 |
| Taper (mm) | ≤0.003/100 | ≤0.003/100 |
| Card position size (mm) | ≤0.003 | ≤0.003 |
| Spindle speed (r/min) | 8 | 8 |
| Handle size (mm) | 20*20 | 20*20 |
| Boring size (mm) | φ20 | φ20 |
| Change knife manner | Random | Random |
| Adjacent change knife time (s) | 0.2 | 0.2 |
| Power (KW) | 5.7 | 6.7 |
| Weight (KG) | 2300 | 2500 |
| Size (L*W*H mm) | 2090*1430*1555 | 2090*1430*1555 |
- Shipping Timeframes: All orders are processed within 2-5 business days (excluding weekends and holidays). After your order has been processed, the estimated delivery time is before 03 Feb, 2026, depending on customs, Please note that due to high demand, some items may experience longer shipping times, which will be communicated at order confirmation email.
- Order Processing Time: Please allow 2-5 business days for us to process your order before it is shipped . Orders placed after 16:00 on Fridays, or during weekends and public holidays, will begin processing on the next business day. Processing times may be extended during peak seasons or sales events.
- Manufacturing Time: Some products needs manufacturing time, the manufacturing process will take approximately 10-30 business days depending on the product. This timeframe may vary depending on the complexity of the product and current demand. but this will be communicated with you during order confirmation.
- Returns and Exchanges: We offer a 30-day return policy for most items. If you are not completely satisfied with your purchase, you may return it within 30 days of receipt for a refund or exchange. Items must be unused, in their original packaging, and accompanied by proof of purchase. Return shipping costs are the responsibility of the customer, unless the item was damaged or defective upon arrival.
1. What types of materials can the DAS Mesin Bubut CNC lathe machine process?
The DAS Mesin Bubut CNC lathe machine is suitable for processing all kinds of small and medium-sized shaft and plate workpieces, as well as producing various threads, circular arcs, circular cones, and both inside and outside surfaces of revolved bodies.
2. What are the key features of the DAS Mesin Bubut CNC lathe machine?
Key features include super rigidity with a one-piece body structure, modern control components, a superb price/performance ratio, user-friendly design, a variety of customization options, and the capability for high efficiency assembly line operation.
3. What control packages are available for this CNC lathe machine?
The DAS Mesin Bubut CNC lathe machine can be equipped with optional control packages such as the FAUNC 0iTF and Siemens 828D, with display options of 8.4' or 10.4'.
4. What is the maximum cutting length of the CNC lathe machine?
The maximum cutting length for the DAS Mesin Bubut CNC lathe machine is 100mm or 200mm, depending on the model.
5. What is the spindle speed range of the CNC lathe?
The spindle speed range is from 45 to 4500 revolutions per minute (r/min) for both CNC36A and CNC46A models.
6. What is the weight of the DAS Mesin Bubut CNC lathe machine?
The CNC36A model weighs 2300 KG, while the CNC46A model weighs 2500 KG.
7. Is there a warranty for the DAS Mesin Bubut CNC lathe machine?
Yes, the DAS Mesin Bubut CNC lathe machine typically comes with a warranty, but specific terms and duration can vary. Please check with the supplier for detailed warranty information.
8. Can the CNC lathe machine be customized with additional features?
Yes, the machine offers a rich choice of additional features including electric turret, servo turret, power turret, upgraded spindle power and torque, and various other enhancements.
9. What safety features are included with the CNC lathe machine?
The DAS Mesin Bubut CNC lathe machine includes a full protective cover and a stainless steel telescope cover, providing a safe and clean working environment.
10. What is the minimum resolution of the CNC lathe machine?
The minimum resolution for both CNC36A and CNC46A models is 0.001 mm.
11. What is the maximum diameter of rotation for this CNC lathe?
The maximum diameter of rotation for both CNC36A and CNC46A models is 310 mm.
12. What industries commonly use the DAS Mesin Bubut CNC lathe machine?
This CNC lathe machine is widely used in industries such as sanitary, valve manufacturing, electrical appliances, instrumentation, automotive, motorcycle production, and bearing manufacturing.
13. How does the assembly line operation work with this CNC lathe?
The advanced truss drive system allows for multiple machines to be combined to complete a task, significantly reducing drive time between processes and increasing overall efficiency.
14. What is the cutting feed rate for the CNC lathe machine?
The cutting feed rate for the DAS Mesin Bubut CNC lathe machine ranges from 0 to 500 mm/min.
15. What dimensions does the CNC lathe machine occupy?
The dimensions for both the CNC36A and CNC46A models are 2090 mm (L) x 1430 mm (W) x 1555 mm (H).
