Concrete Ditch Lining Machine Automatic Road Ditch Forming Equipment Water Canal Equipment
- Section : Machinery
- Category : Road Machinery
- SKU : 1600827987727
Yugong Ditch Laying Machine Quality Cement Ditch Machine
Specification
| Speed material | 1.25mmin |
| Lining walking speed | 1.2m~1.5m/min |
| lining speed | 5-11m/h |
| Thickness lining | 60-160mm |
| Total installed power | 70.5kw |
| Product use | Channel forming |
| Dimension | 2500*1600*1870mm |
| Weight | 2700 kgs |
Product Description
Details & Accessories
Trapezoidal channel automatic vibrating concrete lining machine U shaped concrete automatic ditch channel lining deviceMain technical performance indicatorsAdapt to the site: the bottom of the canal, the slope of the canal, the highway, etc. can be used. Equipment specifications: According to the width of the working surface, the length of the fuselage can be customized.Equipment structure and working principleThe bottom lining machine consists of four parts: the feeding machine, the spreading machine, the screeding machine and the receiving frame. The loading machine is placed on the slope of the channel, the frame is connected with the booth of the spreader, and there is a walking wheel at the bottom of the frame, which does not need to be towed and automatically controls walking. The spreader, the trowel and the receiving frame are placed in parallel at the bottom of the channel and at a certain distance in the middle. The material is placed in the hopper of the loading machine by the tanker, and is fed into the hopper of the spreading machine with the belt, and then fed along the belt of the spreading machine. The material is introduced into the storage hopper through the baffle plate on the belt, and the vibrating plate is spread by the lower part of the rack. Evenly, it is smoothed by a trowel, and the face frame is manually closed.Molding machine featuresHydraulic propelling walking device, good molding effect.High-power vibrator, high density, smooth construction and surface.Generator, stable, low fuel consumption, low cost of use.The failure rate of the whole machine accessories is low.The control box adopts button control, which is easy to operate.The hopper is equipped with a screw
- Shipping Timeframes: All orders are processed within 2-5 business days (excluding weekends and holidays). After your order has been processed, the estimated delivery time is before 03 Feb, 2026, depending on customs, Please note that due to high demand, some items may experience longer shipping times, which will be communicated at order confirmation email.
- Order Processing Time: Please allow 2-5 business days for us to process your order before it is shipped . Orders placed after 16:00 on Fridays, or during weekends and public holidays, will begin processing on the next business day. Processing times may be extended during peak seasons or sales events.
- Manufacturing Time: Some products needs manufacturing time, the manufacturing process will take approximately 10-30 business days depending on the product. This timeframe may vary depending on the complexity of the product and current demand. but this will be communicated with you during order confirmation.
- Returns and Exchanges: We offer a 30-day return policy for most items. If you are not completely satisfied with your purchase, you may return it within 30 days of receipt for a refund or exchange. Items must be unused, in their original packaging, and accompanied by proof of purchase. Return shipping costs are the responsibility of the customer, unless the item was damaged or defective upon arrival.
1. What is the maximum lining speed of the Concrete Ditch Lining Machine?
The maximum lining speed of the Concrete Ditch Lining Machine is 11 meters per hour.
2. What is the thickness range of the concrete lining that this machine can produce?
This machine can produce concrete linings with a thickness range of 60 to 160 mm.
3. What type of channels can this machine be used for?
The machine is adaptable for various types of channels, including the bottom of canals, slopes, and highway ditches.
4. What is the total installed power of the machine?
The total installed power of the Concrete Ditch Lining Machine is 70.5 kW.
5. What are the dimensions of the machine?
The dimensions of the Concrete Ditch Lining Machine are 2500 mm x 1600 mm x 1870 mm.
6. How heavy is the Concrete Ditch Lining Machine?
The machine weighs 2700 kgs.
7. What is the speed of the lining walking mechanism?
The lining walking speed of the machine ranges from 1.2 to 1.5 meters per minute.
8. How does the machine ensure a smooth finish on the concrete surface?
The machine uses a high-power vibrator for high density and smooth construction, along with a trowel for finishing the surface.
9. Is the machine easy to operate?
Yes, the machine features a control box with button controls that make it easy to operate.
10. What components make up the Concrete Ditch Lining Machine?
The machine consists of four main parts: the feeding machine, spreading machine, screeding machine, and receiving frame.
11. Can the machine be customized based on the width of the working surface?
Yes, the length of the fuselage can be customized according to the width of the working surface.
12. How does the loading machine feed material into the system?
The loading machine receives material from a tanker into its hopper and feeds it into the spreading machine via a belt.
13. What is the failure rate of the machine's accessories?
The failure rate of the whole machine's accessories is low, ensuring reliable operation.
14. What type of power source does the machine use?
The machine is equipped with a generator that offers stable operation with low fuel consumption.
15. What is the main advantage of the hydraulic propelling walking device?
The hydraulic propelling walking device enhances the molding effect and allows for automatic movement without towing.
