The CNC Automatic Lathe can accommodate a maximum workpiece length of 2000 mm.
This CNC lathe has a maximum weight capacity of 800 kg for the workpiece.
The CNC Automatic Lathe is equipped with a single spindle.
The positioning accuracy of the CNC lathe is 0.01 mm.
The travel length for the X axis is 1950 mm, and for the Z axis, it is 380 mm.
The spindle speed ranges from 50 to 600 revolutions per minute (r.p.m).
The CNC lathe uses a FANUC control system.
Yes, this CNC lathe is designed for heavy-duty machining with robust capabilities.
The total weight of the CNC Automatic Lathe is 5000 kg.
The CNC lathe requires a power supply of 380V and has a power rating of 5.5 kW.
Yes, a machinery test report is provided with the CNC lathe.
The dimensions of the CNC lathe are 2810 x 1000 x 1275 mm.
Yes, the CNC lathe is fully automatic, offering ease of operation.
The maximum swing over the bed is 410 mm, and over the carriage is 250 mm.
Yes, video outgoing inspection is provided for this CNC lathe.
