Automatic Triaxial Compression Test Apparatus
- Section : Consumer Electronics
- Category : Testing Equipment
- SKU : 1600927624188
Product Display
Products Description
Automatic Soil Triaxial Testing Machine 39.1 61.8
Fully Automatic Triaxial Testing System Apparatus model is adopting the most advanced technology. It is integrated the technology of mechanic, electronic, fully-automated control and sensor automated checking. The range of Triaxial Loading Frame has been designed to be used as part of computer-controlled triaxial system with stress path Triaxial Testing System (V3.11) or as a stand alone unit. Consist of Triaxial Loading Frame and Advanced Pressure Volume Controller (APVC). Both are built up with the LCD graphical display and panel keypad.
IWIN Triaxial Load Frame
Triaxial Load Frame with rigid, durable, low noise and smooth running characteristics,adopts the stepper motor coupled with worn gear drive system to supply the power source. It is equipped with upper and lower limit device; the axial deformation is measured and collected by high-precision displacement sensor. Axial load is measure by force sensors. With overforce protection device, when the axial force loaded is larger than the measuring range of the sensor, the machine will stops working automatically.
Test Module
1.Data Accuisition Module
2.Back Pressure Saturation Test;
3.Consolidation in same direction and consolidation in different direction (pre contact) test;
4.Unconsolidation – undrained test (U-U test);
5.Consolidation – undrained test (C-U test);
6.Consolidation – drainage test (C-U test).
| Model Number | PVC-1 | PVC-2 | PVC-3 |
| Number of channels | 2 | 2 | 1 |
| Maximum Pressure | 2 Mpa | 2 Mpa | 2 Mpa |
| Pressure Resolution | 1 kPa | 1 kPa | 1 kPa |
| Maximum Volume | 60 ml | 150 ml | 200 ml |
| Volume Resolution | 0.001 ml | 0.001 ml | 0.001 ml |
| Precision | +/- 0.1 % F.S. | +/- 0.1 % F.S. | +/- 0.1 % F.S. |
| Confining Pressure | Measuring Range : 0 ~ 2 MPa Resolution : 1 kPa Accuracy : +/- 1 kPa | Measuring Range : 0 ~ 2 MPa Resolution : 1 kPa Accuracy : +/- 1 kPa | Measuring Range : 0 ~ 2 MPa Resolution : 1 kPa Accuracy : +/- 1 kPa |
| Back Pressure | Measuring Range : 0 ~ 2 MPa Resolution : 1 kPa Accuracy : +/- 1 kPa | Measuring Range : 0 ~ 2 MPa Resolution : 1 kPa Accuracy : +/- 1 kPa | Measuring Range : 0 ~ 2 MPa Resolution : 1 kPa Accuracy : +/- 1 kPa |
| Pore Pressure | Measuring Range : 0 ~ 2 MPa Resolution : 1 kPa Accuracy : +/- 0.1% F.S. | Measuring Range : 0 ~ 2 MPa Resolution : 1 kPa Accuracy : +/- 0.1% F.S. | Measuring Range : 0 ~ 2 MPa Resolution : 1 kPa Accuracy : +/- 0.1% F.S. |
| Power | 110-240V, 50Hz | 110-240V, 50Hz | 110-240V, 50Hz |
| Dimension | 870mm (L) x530mm (W) x 320mm (H) | 1010×530×320 | 650X94X123 |
| Weight | 38 kg | 62kg | 80kg |
| Technical Specifications | |||||
| Model Number | SG-1 | SG-3 | SG-5 | SG-10 | SG-20 |
| Maximum Axial Force (Load Sensor) | 10KN | 30KN | 50KN | 100KN | 200KN |
| Maximum Diameter | Ø70mm x 140mm (H) | Ø100mm x 200mm (H) | Ø150mm x 300mm (H) | Ø200mm x400mm (H) | Ø200mm x400mm (H) |
| Testing Speed Rate | 0.00001 - 9.99999 mm/min | 0.00001 - 9.99999 mm/min | 0.00001 - 20mm/min | 0.00001 - 20mm/min | 0.00001 - 9.99999mm/min |
| Precision | +/- 0.1% F.S. | ||||
| Displacement Measuring Range | 50mm | 80mm | 100mm | 150mm | 150mm |
| Maximum Vertical Clearance | 500mm | 540mm | 720mm | 720mm | 670mm |
| (700mm) | (700mm) | ||||
| Horizontal Clearance | 240mm | 300mm | 360mm | 450mm | 610mm |
| Power | 110 or 240V | ||||
| Dimension(mm) | 400×350×830 (mm) | 600×350×1180 (mm) | 600×450×1180 (mm) | 800×520×1660(mm) | 1000×700×2200(mm) |
| Weight(kg) | 45kg | 98kg | 120kg | 240kg | 860kg |
- Shipping Timeframes: All orders are processed within 2-5 business days (excluding weekends and holidays). After your order has been processed, the estimated delivery time is before 03 Feb, 2026, depending on customs, Please note that due to high demand, some items may experience longer shipping times, which will be communicated at order confirmation email.
- Order Processing Time: Please allow 2-5 business days for us to process your order before it is shipped . Orders placed after 16:00 on Fridays, or during weekends and public holidays, will begin processing on the next business day. Processing times may be extended during peak seasons or sales events.
- Manufacturing Time: Some products needs manufacturing time, the manufacturing process will take approximately 10-30 business days depending on the product. This timeframe may vary depending on the complexity of the product and current demand. but this will be communicated with you during order confirmation.
- Returns and Exchanges: We offer a 30-day return policy for most items. If you are not completely satisfied with your purchase, you may return it within 30 days of receipt for a refund or exchange. Items must be unused, in their original packaging, and accompanied by proof of purchase. Return shipping costs are the responsibility of the customer, unless the item was damaged or defective upon arrival.
1. What is the maximum pressure that the Automatic Triaxial Compression Test Apparatus can handle?
The maximum pressure that the apparatus can handle is 2 MPa.
2. What types of tests can be performed using this apparatus?
The apparatus can perform Back Pressure Saturation Test, Consolidation tests in the same and different directions, Unconsolidated Undrained tests (U-U), Consolidated Undrained tests (C-U), and Consolidation Drainage tests.
3. What is the precision of the pressure measurements?
The precision of the pressure measurements is +/- 0.1% of the full scale (F.S.).
4. How does the Automatic Triaxial Compression Test Apparatus ensure safety during operation?
The apparatus features an overforce protection device that automatically stops the machine if the axial force exceeds the measuring range of the sensor.
5. What are the dimensions of the apparatus?
The dimensions of the apparatus vary by model, with the largest being 1010mm (L) x 530mm (W) x 320mm (H).
6. Is the apparatus suitable for computer control?
Yes, the apparatus can be integrated into a computer-controlled triaxial system as well as function as a stand-alone unit.
7. What is the weight of the Automatic Triaxial Compression Test Apparatus?
The weight of the apparatus varies by model, with weights ranging from 38 kg to 860 kg.
8. What power supply does the apparatus require?
The apparatus operates on a power supply of 110-240V at 50Hz.
9. What is the resolution of the volume measurements?
The resolution of the volume measurements is 0.001 ml.
10. Can the apparatus measure axial deformation?
Yes, axial deformation is measured using a high-precision displacement sensor.
11. What is the maximum axial force the apparatus can apply?
The maximum axial force the apparatus can apply varies by model, ranging from 10 kN to 200 kN.
12. How can I control the apparatus?
The apparatus features an LCD graphical display and a panel keypad for easy control and monitoring.
13. What is the maximum volume capacity for testing?
The maximum volume capacity varies by model, with options of 60 ml, 150 ml, and 200 ml.
14. What types of sensors are used in the apparatus?
The apparatus uses force sensors for axial load measurement and high-precision displacement sensors for axial deformation measurement.
15. Is training provided for operating the apparatus?
Training may be available; please contact the manufacturer or supplier for details on training programs.
