Automatic External Defibrillator (AED)

Overview

The Defi®5s Pro AED is designed to deliver reliable, high-quality defibrillation for emergency medical situations. With advanced features like selectable energy levels, voice and visual prompts, and a long-lasting battery, it provides exceptional assistance during critical care situations. This AED is ideal for use in hospitals, clinics, and public spaces with high emergency response needs.

Key Features and Benefits

Selectable Energy Levels:

• Adjustable energy settings of 50, 50, 75 Joules and 150, 150, 200 Joules to tailor the defibrillation to both adult and child patients.

User-Friendly Operation:

• Extensive voice and visual prompts guide the operator through the entire process, ensuring that even untrained personnel can operate the AED effectively.

Multilingual Support:

• Two languages to choose from, with the option for users to switch the language manually for ease of use.

Advanced Self-Testing:

• The AED conducts daily, weekly, and monthly self-tests, ensuring the device is always ready for use.

Infra-Red Data Transmission:

• Equipped with infra-red technology for seamless data transmission, making it easy to share critical ECG signals and event logs with healthcare professionals or computers.

Portability and Convenience:

• Can be used while still in the carrying bag—no need to open it, saving valuable time during emergencies.
• Extra pocket in the bag for storing first aid products.

Water and Dust Resistant:

• IPX55 rating makes the device resistant to water and dust, ensuring functionality in challenging environments.

Long Battery Life:

• Features a disposable LiMnO2 battery that lasts for at least 5 years, ensuring the AED is ready when needed without frequent replacements.

Internal Memory for Event Recording:

• The AED has an internal memory (60 hours) to store ECG signals, event data, and operator actions. This is vital for post-event analysis and reporting.

Detailed Features

Defibrillation Process:

• Three-step process to ensure efficient and safe defibrillation: Analysis, Charge, and Shock delivery.

Lock-Out Protection:

• Prevents inadvertent defibrillation by implementing a lock-out protection system, ensuring safety for both the patient and operator.

Event and ECG Recording:

• Records event types such as shock events, self-tests, CPR start/stop times, etc.
• ECG signals and event logs are transferable to a computer for further analysis.

Waveform Settings:

• Customizable waveform gain settings (5mm/mV, 10mm/mV, 20mm/mV).
• Adjustable waveform speed (12.5mm/s, 25mm/s, 50mm/s) to optimize ECG reading for medical personnel.

Printing ECG:

• Allows for printing ECG directly from the device by entering the print settings interface, providing a physical record of the patient’s condition.

Specifications

Energy Levels:

• 50, 50, 75 Joules (Adult), 150, 150, 200 Joules (Child)

Voice and Visual Prompts:

• Guidance throughout the defibrillation process

Storage:

• 60-hour memory for ECG and event logs

Battery:

• LiMnO2 disposable battery with a 5-year life span

Display:

• Shows ECG waveform, impedance detection, and power parameters

Self-Test:

• Daily, Weekly, and Monthly self-test capabilities

Water and Dust Resistance:

• IPX55 rated

Dimensions (Device):

• Size: Compact, easy-to-handle
• Carrying Case: Includes a practical bag with extra storage space
