50 Kg Affordable Aircrafter Model Dc Motor For 3 Ton Axis Rotating Against Welding Rotators Positioners Assembly Rotary Table
- Section : Machinery
- Category : Welding Equipment
- SKU : 1600198334075
50 Kg Affordable Aircrafter Model Dc Motor For 3 Ton Axis Rotating Against Welding Rotators Positioners Assembly Rotary Table
For Sell Table Manual Welding Positioner Turntable
The positioner is a special welding auxiliary equipment, which is suitable for the welding position of the rotary work to obtain the ideal processing position and welding speed. It can be used with manipulators and welding machines to form an automatic welding center. It can also be used for workpiece displacement during manual operations. The table rotation adopts frequency converter stepless speed regulation, with high speed regulation accuracy. The remote control box can realize the remote operation of the workbench, and can also be connected with the operating machine and the welding machine control system to realize the linkage operation.
The positioner can work together with the welding column and arm to realize the automation of the dedicated welding center.
As a peripheral device of the robot, it can also work with the robot to realize automatic welding.
Automatic tilt positioning machine/turntable series can be divided into side tilting type, head and tail rotating type, head and
tail rack lifting and rotating type, head and tail rack tilting type, and double rotating type positioning machine.
The automatic tilt positioning machine/turntable is mainly composed of a table turning unit and a tilting unit.
The worktable is lifted, tilted and rotated, and the workpiece is fixed on the worktable, which can be placed in the ideal
position for welding and assembly.
We can design custom positioners according to customers' workpieces and welding processes.
Product Details
1. Through rotating or tilting the work table, Block-type positioner is the device making the weld seam in a horizontal or
boat-shaped position.
2. Work table rotate by using frequency conversion stepless, while the sector gear and hydraulic cylinder drive table tilt.
3. Table turning angle is 0 ° ~ 120 °.
Specification
| Model No. | BW-6 | BW-40 | BW-50 | BW-100 | BW-150 | BW-200 | |
| Basic loading(kg) | 600 | 4000 | 5000 | 10000 | 15000 | 20000 | |
| Rotating speed r/min | 0.05-0.5 | 0.03-0.3 | 0.02-0.2 | 0.02-0.2 | 0.02-0.2 | 0.02-0.2 | |
| Turning speed r/min | 0.75 | 0.37 | 0.25 | 0.2 | 0.15 | 0.15 | |
| Turning angle | 0-120 | 0-120 | 0-120 | 0-120 | 0-90 | 0-90 | |
| Work table diameter(mm) | 800 | 1400 | 1600 | 2000 | 2200 | 2500 | |
| Height of work table(mm) | 1000 | 1600 | 1800 | 2100 | 2300 | 2600 | |
| Allow workpiece | Eccentricity | 150 | 200 | 200 | 200 | 200 | 200 |
| off-center(mm) | Centroidal distance | 200 | 300 | 300 | 540 | 500 | 600 |
| Rotating motor power(kw) | 0.37 | 2.2 | 2.2 | 5.5 | 4 | 5.5 | |
| Turning motor power(kw) | 0.75 | 3 | 3 | 3 | 7.5 | 11 | |
- Shipping Timeframes: All orders are processed within 2-5 business days (excluding weekends and holidays). After your order has been processed, the estimated delivery time is before 03 Feb, 2026, depending on customs, Please note that due to high demand, some items may experience longer shipping times, which will be communicated at order confirmation email.
- Order Processing Time: Please allow 2-5 business days for us to process your order before it is shipped . Orders placed after 16:00 on Fridays, or during weekends and public holidays, will begin processing on the next business day. Processing times may be extended during peak seasons or sales events.
- Manufacturing Time: Some products needs manufacturing time, the manufacturing process will take approximately 10-30 business days depending on the product. This timeframe may vary depending on the complexity of the product and current demand. but this will be communicated with you during order confirmation.
- Returns and Exchanges: We offer a 30-day return policy for most items. If you are not completely satisfied with your purchase, you may return it within 30 days of receipt for a refund or exchange. Items must be unused, in their original packaging, and accompanied by proof of purchase. Return shipping costs are the responsibility of the customer, unless the item was damaged or defective upon arrival.
1. What is this product?
This is a welding positioner / rotary turntable assembly that uses an Aircrafter DC motor (marketed as the '50 Kg Affordable Aircrafter Model') to rotate and tilt workpieces. It's designed as an auxiliary device for welding rotators, manipulators, robots and manual welding to obtain ideal welding positions and speeds.
2. What load capacities and workpiece sizes does the unit support?
The product family covers a range of models designed for different load capacities and table diameters. Models in the series are intended to handle light to heavy workpieces (including setups up to several tons when configured as a rotator/positioner). Exact allowable load, table diameter and centroidal/off-center limits depend on the specific model — please provide the model number or workpiece details for a precise match.
3. What kinds of motion and angles are supported?
The positioner provides continuous rotation (worktable rotation) with frequency-converter stepless speed control and a tilting function driven by sector gear and hydraulic cylinder. Typical tilt angles are 0° to 120° for most types; some heavy or special models use 0°–90°. Exact ranges depend on the selected model.
4. How is the rotation speed controlled?
Rotation uses a frequency converter (inverter) for stepless speed regulation, delivering high speed regulation accuracy. The unit can be controlled locally or via the remote control box.
5. Can the unit be connected to welding machines or robots for automated operation?
Yes. The remote control box supports remote operation and the positioner can be integrated with a welding machine control system or a robotic cell to enable linked or automatic welding sequences.
6. What motor type and power are used?
The system uses a DC (Aircrafter model) motor for rotation. Motor power and exact specifications vary by model and load requirement. Please specify your load, desired table size and rotational/turning speed so we can recommend the correct motor and power rating.
7. What positioning/tilting types are available?
The series includes multiple configurations: side-tilting type, head-and-tail rotating type, head-and-tail rack lifting & rotating type, head-and-tail rack tilting type, and double-rotating type. Custom designs can be provided for special workpieces or welding processes.
8. Is customization available for odd-shaped or large workpieces?
Yes. The manufacturer can design custom positioners based on customers' specific workpieces and welding process requirements (table size, mounting fixtures, drive power, control integration, etc.).
9. What safety features should I expect?
Standard safety measures include secure workpiece clamping, emergency stop wiring, stable base anchoring, overload protection (when integrated with the motor drive), and controlled tilt/rotation speeds. Additional safety interlocks can be added per customer request.
10. What are the installation requirements?
Installation requires a level, rigid foundation, correct mechanical anchoring, proper electrical supply for the inverter and motor, and grounding. Lifting and mounting fixtures must match your workpiece. We recommend professional installation by trained technicians or field service from the supplier.
11. What routine maintenance is required?
Regular maintenance includes keeping the turntable and gears lubricated, inspecting and tightening fasteners, checking electrical connections and inverter/motor health, monitoring hydraulic components if fitted, and replacing worn drive components or seals as needed. Follow the manufacturer's maintenance schedule for intervals.
12. How do I choose the correct model for my application?
Provide the following details: workpiece weight, diameter, centroid/off-center distance, required rotation and tilt angles, desired rotation speed range, and whether you need robot/welder integration. With that information the supplier can recommend a model or a custom design.
13. What is the typical lead time and warranty?
Lead time and warranty terms vary by supplier, model and customizations. Contact the seller or manufacturer with your configuration so they can provide accurate lead times, delivery options and warranty coverage.
14. Can spare parts and service be supplied?
Yes. Spare parts (motors, inverters, gears, hydraulic components, control boxes) and after-sales service are typically available from the manufacturer or authorized distributors. Provide the model number and part descriptions when requesting parts or service.
15. How do I request a quote or technical drawings?
Contact the supplier with your application details (workpiece weight/size, required motions/speeds, installation constraints and any automation interfaces). The supplier will provide a quotation, specifications and technical drawings or offer a custom design if needed.
