The lifting capacity varies by model: PFP27 can lift up to 2700 kg, while PFP36 can lift up to 3600 kg.
The maximum lifting height is either 1800 mm or 2000 mm, depending on the model chosen.
The system is driven by a hydraulic mechanism utilizing a steel rope lifting system for safe and efficient operation.
The lift includes anti-falling mechanical locks, automatic locks, and manual/electric lock release for enhanced safety.
The rise time is approximately 70 seconds, and the drop time is around 60 seconds.
The lift features high polymer polyethylene slide blocks, diamond steel plates for the platform and ramps, and galvanized steel plates.
The installation space required is 4800 mm x 2700 mm x 2100 mm.
Yes, the lock can be manually unlocked by pushing the handle during the descent period.
The lift operates on a power supply of 220 V / 380 V, 50 Hz / 60 Hz, with options for 1 Phase or 3 Phase and a motor capacity of 2.2 Kw.
The lift is designed to accommodate a variety of vehicles, but it's important to check the specific lifting capacity and dimensions to ensure compatibility.
The drive-through width is 1900 mm, allowing for easy access to the lift.
Steel parts are sandblasted, then coated with an anti-corrosion primer and a top finish color coat to enhance durability.
Yes, the lift includes movable galvanized steel plates in the middle to accommodate various vehicle sizes and enhance versatility.
For any issues, please refer to the user manual for troubleshooting steps or contact customer support for assistance.
While it is possible to install it yourself, professional installation is recommended to ensure safety and proper functionality.
