RLG12 Log Grapple
The RLG12 Log Grapple is a specialized tool designed for efficient handling of logs and heavy materials in forestry and agricultural applications. Engineered for strength and durability, this grapple is ideal for use on farms and in forestry settings.
Key Features
- Robust Construction: Made with high-quality materials to ensure durability and performance in demanding environments.
- Weight: Weighing just 53 kg, the grapple is lightweight yet sturdy, making it easy to operate without sacrificing strength.
- Core Components: Equipped with a powerful motor and cylinder, providing reliable performance and efficiency.
- Non-Rotary/Rotary Options: Available in both non-rotary and rotary types, allowing for flexibility depending on operational needs.
- High Grabbing Force: Offers a grabbing force of 6.3 KN, ensuring secure handling of heavy materials.
- Max Grabbing Weight: Capable of handling a maximum weight of 500 kg, making it suitable for large logs and other heavy materials.
- Working Pressure: Operates at a working pressure of 17.5 Mpa, delivering consistent performance.
- Certification: CE and ISO certified, ensuring compliance with industry standards for safety and quality.
- Video Outgoing Inspection: A video inspection is provided to guarantee quality assurance before delivery.
- Machinery Test Report: A test report is included, confirming the grapple’s reliability and performance.
The RLG12 Log Grapple is a reliable choice for anyone in the forestry or agricultural industry, enhancing productivity and efficiency in material handling tasks.
Product Info Gallery
Discover how the RLG12 Log Grapple can streamline your operations and improve handling capabilities in forestry and farm applications!
1. The Log grapple is widely used for forestry machines- logger loaders, timber trailers, timber cranes, tractor cranes, and excavators.
2. It is made of wear-resistant steel, light in texture, wear-resistant, large in grip, flexible and light in operation.3. Imported rotary motor is adopted, with long service life.
4. The oil cylinder adopts grinding tube and imported oil seal, which has short working cycle and long service life.
Select Model
| Specification: (Log Grapple) | ||||||||
| Model | Unit | 0.12m2 | 0.16m2 | 0.19m2 | 0.22m2 | 0.24m2 | 0.36m2 | 0.45m2 |
| Excavator Carrier | T | 1-2 | 3-6 | 7-10 | 7-10 | 7-10 | 10-20 | ＞20 |
| Weight | KG | 53 | 73 | 110 | 115 | 145 | 235 | 365 |
| Rotary Motor Pin Control | 50 | 50 | 50/60 | 60 | 60 | 60 | 60 | |
| Working Pressure | Mpa | 17.5 | 17.5 | 17.5 | 21 | 21 | 22 | 22 |
| Grabbing Force | KN | 6.3 | 7 | 8.25 | 9.2 | 11 | 13.1 | 13.1 |
| Max Grabbing Weight | KG | 500 | 1000 | 1500 | 1500 | 2000 | 2500 | 4000 |
| Model | Unit | 0.12m2 | 0.16m2 | 0.19m2 | 0.22m2 | 0.24m2 | 0.36m2 | 0.45m2 |
| A | mm | 50 | 50 | 50 | 60 | 60 | 60 | 60 |
| B | mm | 630 | 700 | 760 | 790 | 815 | 806 | 1000 |
| C | mm | 800 | 1040 | 1260 | 1305 | 1275 | 1620 | 1950 |
| D | mm | 960 | 1210 | 1380 | 1445 | 1470 | 1746 | 2200 |
| E | mm | 425 | 480 | 505 | 515 | 525 | 605 | 760 |
| F | mm | 550 | 720 | 760 | 785 | 785 | 870 | 1025 |
| G | mm | 680 | 720 | 800 | 820 | 860 | 1000 | 1220 |
| H | mm | 280 | 275 | 368 | 368 | 390 | 440 | 518 |
| I | mm | 60 | 75 | 60 | 65 | 95 | 130 | |
| * |
| Specification: (Wood/Stone Grapple) | ||||||||
| Model | Unit | RHG01 | RHG03 | RHG04 | RHG06 | RHG08 | RHG10 | RHG14 |
| Weight | Kg | 100 | 250 | 390 | 740 | 1380 | 1700 | 1900 |
| Jaw opening | mm | 800 | 1100 | 1400 | 1800 | 2300 | 2500 | 2500 |
| Working pressure | Kg/cm² | 80-100 | 110-140 | 120-160 | 150-170 | 160-180 | 160-180 | 180-200 |
| Setting pressure | Kg/cm² | 160 | 170 | 180 | 190 | 200 | 210 | 250 |
| Oil flow | l/m | 20-40 | 30-55 | 50-100 | 90-110 | 100-140 | 130-170 | 200-250 |
| Cylinder | pcs | 3.0 x 2 | 4.0 x 2 | 4.5 x 2 | 8.0 x 2 | 9.7 x 2 | 12 x 2 | 14 x 2 |
| Carrier | ton | 1-3 | 4 - 5 | 6-11 | 12-16 | 17-23 | 24-30 | 33-45 |
| * |
| Specification: (Steel Scrap Grapple) | |||||
| Model | unit | RHGP-04 | RHGP-06 | RHGP-08 | RHGP-10 |
| Weight | Kg | 510 | 1200 | 1560 | 1800 |
| Max jaw opening | mm | 1750 | 1780 | 1950 | 2180 |
| Pressure | bar | 260 | 260 | 260 | 260 |
| Oil flow | l/m | 20-70 | 60-120 | 60-120 | 60-120 |
| Grab weight | Kg | 800 | 1000 | 1300 | 1700 |
| No.of Jaw | pcs | 4-5 | 4-5 | 4-5 | 4-5 |
| Excavator | ton | 5-11 | 12-18 | 18-25 | 26-35 |
| * This specifications are subject to change without prior notice for the improvement of quality. |
| Specification: (Steel Scrap Grapple) | |||||||||
| Model | Unit | RCG-mini | RCG-02 | RCG-04 | RCG-06A | RCG-06B | RCG-08 | RCG-10 | RCG-14 |
| Carrier | Ton | 2.5-4.5 | 4-6 | 6-8 | 10-15 | 15-18 | 18-21 | 22-27 | 28-37 |
| Cylinder | Bar | 250 | 300 | 350 | 350 | 350 | 350 | 350 | 350 |
| Liters/min | 8-15 | 10-20 | 15-30 | 30-65 | 40-80 | 55-110 | 55-110 | 95-165 | |
| 360° Rotation | Bar | 100 | 100 | 100 | 140 | 140 | 140 | 140 | 140 |
| Liters/min | 6-9 | 8-12 | 8-12 | 12-20 | 12-20 | 14-20 | 14-20 | 28-40 | |
| Tr/min | 10/15 | 10/15 | 10/15 | 10/15 | 10/15 | 10/15 | 10/15 | 10/15 | |
| Force | N | 12000 | 19000 | 25000 | 40000 | 50000 | 60000 | 62000 | 93000 |
| A | mm | 1090 | 1180 | 1290 | 1710 | 1845 | 2000 | 2100 | 2270 |
| B | mm | 770 | 850 | 960 | 1245 | 1375 | 1440 | 1465 | 1630 |
| C | mm | 770 | 840 | 910 | 905 | 1000 | 1050 | 1190 | 1275 |
| D | mm | 760 | 850 | 930 | 1080 | 1100 | 1290 | 1375 | 1425 |
| L | mm | 400 | 460 | 550 | 800 | 900 | 1010 | 1130 | 1210 |
| Volume | L | 77 | 105 | 147 | 395 | 470 | 700 | 820 | 1080 |
| Weight | Kg | 210 | 260 | 370 | 745 | 950 | 1230 | 1500 | 2100 |
| * This specifications are subject to change without prior notice for the improvement of quality. |
- Shipping Timeframes: All orders are processed within 2-5 business days (excluding weekends and holidays). After your order has been processed, the estimated delivery time is before 04 Feb, 2026, depending on customs, Please note that due to high demand, some items may experience longer shipping times, which will be communicated at order confirmation email.
- Order Processing Time: Please allow 2-5 business days for us to process your order before it is shipped . Orders placed after 16:00 on Fridays, or during weekends and public holidays, will begin processing on the next business day. Processing times may be extended during peak seasons or sales events.
- Manufacturing Time: Some products needs manufacturing time, the manufacturing process will take approximately 10-30 business days depending on the product. This timeframe may vary depending on the complexity of the product and current demand. but this will be communicated with you during order confirmation.
- Returns and Exchanges: We offer a 30-day return policy for most items. If you are not completely satisfied with your purchase, you may return it within 30 days of receipt for a refund or exchange. Items must be unused, in their original packaging, and accompanied by proof of purchase. Return shipping costs are the responsibility of the customer, unless the item was damaged or defective upon arrival.
1. What applications is the RLG12 Log Grapple suitable for?
The RLG12 Log Grapple is ideal for forestry and agricultural applications, including use on logger loaders, timber trailers, timber cranes, tractor cranes, and excavators.
2. What is the weight of the RLG12 Log Grapple?
The RLG12 Log Grapple weighs 53 kg, making it lightweight yet sturdy for easy operation.
3. What type of materials can the RLG12 Log Grapple handle?
This grapple can handle heavy materials, including logs, with a maximum grabbing weight of 500 kg.
4. What is the grabbing force of the RLG12 Log Grapple?
The RLG12 Log Grapple offers a grabbing force of 6.3 KN, ensuring secure handling of materials.
5. Are there different options available for the RLG12 Log Grapple?
Yes, the RLG12 Log Grapple is available in both non-rotary and rotary options, providing flexibility based on operational needs.
6. What is the working pressure of the RLG12 Log Grapple?
The grapple operates at a working pressure of 17.5 Mpa, delivering consistent performance.
7. Is the RLG12 Log Grapple certified for safety and quality?
Yes, the RLG12 Log Grapple is CE and ISO certified, ensuring compliance with industry standards for safety and quality.
8. What kind of inspection is provided before delivery?
A video outgoing inspection is provided to guarantee quality assurance before delivery.
9. What kind of machinery test report comes with the RLG12 Log Grapple?
A machinery test report is included, confirming the grapple’s reliability and performance.
10. What materials is the RLG12 Log Grapple made of?
The grapple is made of wear-resistant steel, designed for durability and performance in demanding environments.
11. How does the RLG12 Log Grapple enhance operational efficiency?
The RLG12 Log Grapple is engineered for strength, featuring a powerful motor and cylinder which improve handling capabilities and productivity in material handling tasks.
12. Can the RLG12 Log Grapple be used with different excavator sizes?
Yes, the grapple is compatible with various excavator sizes, making it a versatile tool for different machinery.
13. What is the jaw opening size of the RLG12 Log Grapple?
The jaw opening size varies depending on the model, with options available to accommodate different material sizes.
14. What is the lifespan of the components in the RLG12 Log Grapple?
The grapple is equipped with an imported rotary motor and a high-quality oil cylinder, both designed for long service life and reduced working cycles.
15. Is the operation of the RLG12 Log Grapple user-friendly?
Yes, the grapple is designed to be flexible and easy to operate, making it suitable for users of varying experience levels.
