QIANXUN SE Base and Rover Differential GPS Receiver:
- Section : Consumer Electronics
- Category : Test Instruments
- SKU : 1600953569949
QIANXUN SE GNSS RTK Base and Rover Differential GPS Receiver
The QIANXUN SE GNSS RTK is a high-performance differential GPS receiver designed for accurate geospatial measurements. This dual-frequency receiver is ideal for applications that require precise location data, such as surveying, mapping, and construction. With a long working range and multiple configuration options, it provides reliable and real-time positioning data for any professional needing high accuracy.
Key Features:
- Dual Frequency GPS: Supports GPS L1 C/A, L2E, L2C, and L5 frequencies for enhanced accuracy and reliability.
- 220 Channels: Offers 220 channels for improved signal tracking and better performance in challenging environments.
- Adjustable Transmitting Power: Choose from 0.5W, 1W, or 2W transmitting power, depending on your operational needs.
- Extended Range: Typical working range of 5 km, with optimal performance up to 8-10 km.
- Long Battery Life: Internal battery supports up to 12 hours of static operation for extended use in the field.
- Clear LCD Display: Features an easy-to-read LCD display for monitoring and managing settings.
- High-Speed Data Transmission: Transmitting speeds of 9.6Kbps and 19.2Kbps for efficient data communication.
| project | subproject | describe |
| GNSS | number of channels | 800 |
| performance | tracking feature | BDS-2: B1, B2, B3 |
| BDS-3: B1C, B2a, B2b, ACEBOC | ||
| GPS: L1C/A, L1C, L1P, L2C, L2P, L5 | ||
| GLONASS: G1,G2,G3 | ||
| Galileo: E1, E5a, E5b, AltBOC, E6 | ||
| QZSS:L1C/A,L1C, L2C, L5, LEX | ||
| data output | NMEA0183, NMEA2000, Crescent binary | |
| Differential output | RTCM SC-104(SBAS/Beacon) has its own differential format ROX, | |
| RTCM2.x, RTCM3.x, CMR, CMR+ | ||
| Accuracy Index | Static measurement | Level: ±(2.5+0.5×10-6D) mm |
| Vertical: ±(5+0.5×10-6D) mm | ||
| RTK measurement | Level: ±(8+1×10-6D) mm | |
| Vertical: ±(15+1×10-6D) mm | ||
| Inertial navigation measurement (need to be activated separately) | Compensation accuracy | 8mm+0.3mm/°tilt (<2cm within 30°) |
| Compensation position | 0~70° | |
| Inertial navigation update rate | 200Hz | |
| System platform | operating system | Linux |
| Built-in storage | Onboard 8G | |
| V2.1+EDR / V4.0 Dual Mode, Class2 | ||
| Wi-Fi | 802.11 b/g/n | |
| Global Radio | Protocol | TrimTalk, TrimMaskⅢ, SOUTH, PCCEOT, |
| Geotalk, Hitarget | ||
| frequency | 410-470MHz | |
| number of channels | 7+2400 (7 fixed channels, 2400 customizable channels) | |
| external radio | 5W/35W adjustable | |
| Electrical properties | Battery | Built-in smart lithium battery, 6800mAh, 7.2V |
| Input voltage | 9~28V DC | |
| Human-computer interaction | button | The power button is used to turn the host on and off. |
| Short press once to broadcast the current working mode and status. | ||
| Data interface | TNC interface | Connecting the built-in radio antenna |
| 5-pin interface | Used to connect external power supply and external radio. | |
| Type-C | For direct charging, data transfer. | |
| physical index | size | 140mm×140mm×71mm |
| weight | 1100g | |
| Environmental performance | Operating temperature | -30℃~+70℃ |
| storage temperature | -40℃~+80℃ | |
| Waterproof and dustproof | IP68 | |
| Anti-drop | 2 meters drop with the pole (concrete hard ground) | |
| humidity | Resist 99% condensation | |
| project | subproject | describe |
| Handbook basic parameters | model | P9Ⅲ |
| operating system | Android 9 | |
| processor | Qualcomm octa-core 64-bit | |
| RAM+ROM | 2GB high-speed DDR3+16GB | |
| external storage | Maximum support 512GB SD expansion | |
| sensor | Electronic Compass, Electronic Bubble, Gravity Sensor | |
| Camera | 13 million autofocus camera | |
| mobile network | Mobile, Telecom, Unicom 4G full Netcom | |
| WiFi/ | 802.11b/g/n,4.1+ LE | |
| Built-in battery | 6000mAh, 3.8V, 22.8Wh | |
| Protection class | IP67 | |
| fall | Withstands a 1.2-meter drop from a hard floor | |
| operating temperature | -30℃~+60℃ | |
| storage temperature | -40℃~+80℃ |
The QIANXUN SE GNSS RTK is designed to provide high-precision positioning for a wide range of applications. Whether you're in surveying, agriculture, or construction, this receiver ensures accurate and reliable results to meet your project’s demands.
Product Info Gallery
- Shipping Timeframes: All orders are processed within 2-5 business days (excluding weekends and holidays). After your order has been processed, the estimated delivery time is before 26 Dec, 2025, depending on customs, Please note that due to high demand, some items may experience longer shipping times, which will be communicated at order confirmation email.
- Order Processing Time: Please allow 2-5 business days for us to process your order before it is shipped . Orders placed after 16:00 on Fridays, or during weekends and public holidays, will begin processing on the next business day. Processing times may be extended during peak seasons or sales events.
- Manufacturing Time: Some products needs manufacturing time, the manufacturing process will take approximately 10-30 business days depending on the product. This timeframe may vary depending on the complexity of the product and current demand. but this will be communicated with you during order confirmation.
- Returns and Exchanges: We offer a 30-day return policy for most items. If you are not completely satisfied with your purchase, you may return it within 30 days of receipt for a refund or exchange. Items must be unused, in their original packaging, and accompanied by proof of purchase. Return shipping costs are the responsibility of the customer, unless the item was damaged or defective upon arrival.
1. What is the accuracy level of the QIANXUN SE GNSS RTK receiver?
The QIANXUN SE GNSS RTK receiver offers a static measurement accuracy of ±(2.5+0.5×10-6D) mm and a vertical accuracy of ±(5+0.5×10-6D) mm. For RTK measurements, the level of accuracy is ±(8+1×10-6D) mm and ±(15+1×10-6D) mm vertically.
2. What types of applications can the QIANXUN SE GNSS RTK receiver be used for?
The QIANXUN SE GNSS RTK receiver is suitable for various applications including surveying, mapping, agriculture, and construction, where high-precision positioning is required.
3. How long does the battery last on the QIANXUN SE GNSS RTK receiver?
The internal smart lithium battery of the QIANXUN SE GNSS RTK receiver supports up to 12 hours of static operation, allowing for extended use in the field.
4. What is the typical working range of the receiver?
The typical working range of the QIANXUN SE GNSS RTK receiver is 5 km, with optimal performance achievable up to 8-10 km.
5. What are the frequency bands supported by the QIANXUN SE GNSS RTK receiver?
The QIANXUN SE GNSS RTK receiver supports multiple frequency bands including GPS L1 C/A, L2E, L2C, L5, and additional frequencies from BDS, GLONASS, Galileo, and QZSS.
6. Is the QIANXUN SE GNSS RTK receiver waterproof?
Yes, the QIANXUN SE GNSS RTK receiver has an IP68 rating, making it waterproof and dustproof, suitable for use in harsh environmental conditions.
7. What kind of data output formats does the receiver support?
The QIANXUN SE GNSS RTK receiver supports various data output formats including NMEA0183, NMEA2000, and Crescent binary. It also supports differential output formats like RTCM SC-104 and others.
8. How many channels does the QIANXUN SE GNSS RTK receiver have?
The QIANXUN SE GNSS RTK receiver offers a total of 220 channels for improved signal tracking and performance in challenging environments.
9. Can the transmitting power be adjusted on the receiver?
Yes, the transmitting power of the QIANXUN SE GNSS RTK receiver can be adjusted to 0.5W, 1W, or 2W based on operational needs.
10. What is the operating temperature range for the receiver?
The QIANXUN SE GNSS RTK receiver can operate within a temperature range of -30℃ to +70℃.
11. What are the dimensions and weight of the QIANXUN SE GNSS RTK receiver?
The dimensions of the QIANXUN SE GNSS RTK receiver are 140mm × 140mm × 71mm, and it weighs approximately 1100g.
12. Does the receiver come with any built-in storage?
Yes, the QIANXUN SE GNSS RTK receiver has built-in storage of 8GB.
13. What type of user interface does the QIANXUN SE GNSS RTK receiver have?
The QIANXUN SE GNSS RTK receiver features a clear LCD display for easy monitoring and management of settings, along with a power button for user interaction.
14. What is the data transmission speed of the receiver?
The QIANXUN SE GNSS RTK receiver supports high-speed data transmission with speeds of 9.6Kbps and 19.2Kbps.
15. Is the QIANXUN SE GNSS RTK receiver suitable for use in agricultural applications?
Yes, the QIANXUN SE GNSS RTK receiver is designed to provide high-precision positioning, making it suitable for agricultural applications such as precision farming.
