80GHz Radar Level Transmitter for Corrosive Chemicals
- Section : Consumer Electronics
- Category : Measuring & Gauging Tools
- SKU : 1601214229837
80GHz Radar Level Transmitter for Corrosive Chemicals
The 80GHz Intelligent Anti-Corrosion Lens Antenna Radar Level Sensor offers a precise and reliable solution for level measurement in chemical, metallurgical, and food processing industries. Built with advanced materials and cutting-edge radar technology, this transmitter ensures accurate results even in challenging environments with corrosive chemicals.
Key Features:
- Anti-Corrosion Construction: The PTFE material and composite flange design resist chemical corrosion, making it ideal for harsh applications.
- Advanced Measurement Technology: Operates at 80GHz for highly accurate level detection with a precision of ±2mm.
- Versatile Measuring Range: Available in options up to 10m, 20m, or 35m to suit diverse needs.
- Temperature Resilience: Functions efficiently in extreme temperatures from -40°C to +200°C, ensuring reliability across a variety of conditions.
- Durable Design: Equipped with an IP67-rated aluminum housing for superior protection against dust and moisture.
- Flexible Signal Output: Supports 4-20mA and HART protocol for seamless integration into existing systems.
- Pressure Resistance: Withstands pressures ranging from -0.1MPa to +2.5MPa, suitable for both low and high-pressure environments.
- Broad Industry Application: Ideal for chemical processing, wastewater treatment, food production, and metallurgical operations.
| Model number | VRPWRD82 |
| Features | Composite flange type anti-corrosion lens antenna, small beam angle, strong focusing ability, high precision. |
| Applications | Level measurement of various liquids in different kinds of tanks or containers in chemical, metallurgical, food processing, waste water and other industries. (For example: hydrochloric acid, nitric acid, sulfuric acid, lye, etc.) |
| Measuring range | 10m/20m/35m |
| Accuracy | ±2mm |
| Process temperature | -40℃ - +200℃ |
| Process connection | Composite Flange |
| Process pressure | -0.1 - +2.5MPa |
| Operating frequency | 80GHZ |
| Signal supply | 4- 20mA/HART protocol |
| Power supply | 24V DC two-wire /four-wire; 220V AC four-wire |
| Explosion-proof grade | Ex ia IIC T6 Ga; Ex d IIC T6 Gb |
| Enclosure protection grade | IP68 (stainless steel aluminum housing), IP67 (aluminum housing) |
Technical Specifications:
- Brand: V-RIVER
- Model Number: VRPWRD82
- Material: PTFE (lens antenna)
- Signal Output: 4-20mA / HART protocol
- Measuring Range: 10m / 20m / 35m
- Accuracy: ±2mm
- Operating Frequency: 80GHz
- Power Supply: 24V DC (two-wire/four-wire), 220V AC (four-wire)
- Process Connection: Composite flange
- Temperature Range: -40°C to +200°C
- Process Pressure: -0.1MPa to +2.5MPa
- Enclosure Protection: IP67
Conclusion:
The 80GHz Intelligent Anti-Corrosion Radar Level Sensor provides unmatched precision and durability for level monitoring in environments exposed to corrosive chemicals. Its advanced features and robust design make it an indispensable tool for industries requiring high-performance measurement solutions.
Product Info Gallery
Product Size
- Shipping Timeframes: All orders are processed within 2-5 business days (excluding weekends and holidays). After your order has been processed, the estimated delivery time is before 26 Dec, 2025, depending on customs, Please note that due to high demand, some items may experience longer shipping times, which will be communicated at order confirmation email.
- Order Processing Time: Please allow 2-5 business days for us to process your order before it is shipped . Orders placed after 16:00 on Fridays, or during weekends and public holidays, will begin processing on the next business day. Processing times may be extended during peak seasons or sales events.
- Manufacturing Time: Some products needs manufacturing time, the manufacturing process will take approximately 10-30 business days depending on the product. This timeframe may vary depending on the complexity of the product and current demand. but this will be communicated with you during order confirmation.
- Returns and Exchanges: We offer a 30-day return policy for most items. If you are not completely satisfied with your purchase, you may return it within 30 days of receipt for a refund or exchange. Items must be unused, in their original packaging, and accompanied by proof of purchase. Return shipping costs are the responsibility of the customer, unless the item was damaged or defective upon arrival.
1. What types of chemicals can the 80GHz Radar Level Transmitter measure?
The transmitter is designed to measure various corrosive chemicals such as hydrochloric acid, nitric acid, sulfuric acid, and lye, making it suitable for chemical processing applications.
2. What is the maximum measuring range of this radar level transmitter?
The 80GHz Radar Level Transmitter offers measuring range options of up to 10m, 20m, or 35m to suit different application needs.
3. What is the accuracy of the level measurement?
This transmitter provides a high level of accuracy with a precision of ±2mm.
4. What materials are used in the construction of the sensor?
The sensor features an anti-corrosion lens antenna made from PTFE material, as well as a composite flange design to resist chemical corrosion.
5. What temperature range can the device operate in?
The radar level transmitter functions efficiently in extreme temperatures ranging from -40°C to +200°C.
6. Is the 80GHz Radar Level Transmitter suitable for outdoor use?
Yes, it is equipped with IP67-rated aluminum housing which provides superior protection against dust and moisture, making it suitable for outdoor applications.
7. What kind of signal output does this transmitter support?
It supports 4-20mA and HART protocol for seamless integration into existing control systems.
8. What is the process pressure range for this transmitter?
The transmitter can withstand pressures ranging from -0.1MPa to +2.5MPa, accommodating both low and high-pressure environments.
9. Is this device explosion-proof?
Yes, the 80GHz Radar Level Transmitter has an explosion-proof grade of Ex ia IIC T6 Ga and Ex d IIC T6 Gb.
10. What power supply options are available for this device?
The device can be powered by a 24V DC two-wire or four-wire system, or a 220V AC four-wire setup.
11. What industries can benefit from using this radar level transmitter?
It is ideal for various industries including chemical processing, wastewater treatment, food production, and metallurgical operations.
12. How does the radar level measurement technology work?
The 80GHz radar technology utilizes high-frequency signals to detect the level of liquids, providing accurate and reliable measurements even in challenging conditions.
13. What is the model number of this product?
The model number of the radar level transmitter is VRPWRD82.
14. Can this transmitter be used for both liquids and solids?
This product is specifically designed for liquid level measurement, particularly in corrosive environments.
15. What kind of maintenance is required for this device?
Regular checks for calibration and ensuring the sensor is free from obstructions are recommended to maintain performance.
