The model number is SS330.
The dimensions are L830 x W1350 x H1430 mm.
The machine weighs approximately 380 kg.
The machine can handle PCB thicknesses from 0.2 mm to 6.0 mm.
The maximum PCB weight that the machine can support is less than 5 kg.
The power supply requirement is 220±10%, 50/60HZ.
The operator power consumption ranges from 1 to 3 kW.
The flux storage tank has a capacity of 1 liter.
The air source flow rate is between 8 to 12 L/min.
The spray precision of the machine is 0.1 mm.
Key features include high precision wave soldering, user-friendly controls, compact design, fast soldering process, and durable components.
This machine is ideal for electronics manufacturing, small to medium production runs, PCB assembly for various devices, DIY projects, and industrial applications.
Yes, the machine is designed to be easy to operate with user-friendly controls.
Yes, the machine is built for fast soldering processes, which can significantly improve efficiency.
Yes, the Wave Solder Automatic DIP Selective Wave Solder Machine is suitable for both DIY projects and industrial applications.
