The Ultra-high Pressure Pumping Technology Concrete Trailer Pump comes with a two-year warranty.
The maximum theoretical concrete output of the pump is 20m³/h.
This concrete pump is powered by a diesel engine.
The dimensions of the pump are 4150mm (L) x 1800mm (W) x 1725mm (H).
The maximum concrete pumping pressure of this pump is 8Mpa.
The pump can convey concrete horizontally up to 300 meters.
The hopper capacity of the Ultra-high Pressure Pumping Technology Concrete Trailer Pump is 300 liters.
Yes, a machinery test report is provided with the pump.
The concrete trailer pump is available in Blue, Black, Green, Yellow, and White.
The weight of the pump is 2800 kg.
The core components include the Bearing, Pump, and Gearbox.
This concrete pump can be used in construction sites for building foundations, roadwork, concrete pouring in remote areas, large-scale industrial applications, and residential and commercial construction.
The pump features a compact design that makes it easy to transport.
The pump uses an S valve type distribution valve.
The concrete cylinder diameter of the Ultra-high Pressure Pumping Technology Concrete Trailer Pump is 120mm.
