The BL-1200A can produce bottles with a maximum volume of 2.5 liters.
The BL-1200A features 8 cavities for efficient production.
The theoretical capacity of the BL-1200A is 6000 bottles per hour.
The machine measures 4.2m x 2m x 2.2m and weighs between 4000 to 6200 kg.
The machine requires a total power supply of 95 kW, with a maximum heating power of 80 kW and a motor power of 15 kW.
The operation pressure for the air compressor is set at 7 bar.
The blowing pressure for the BL-1200A is 35 bar.
The high pressure air consumption is 8500 liters per minute.
The mould cooling water operates at a temperature range of 10-12 degrees Celsius.
The flow rate for the mould cooling water is 60 liters per minute.
Yes, the machine can handle bottles with a maximum outer diameter of 115 mm and a height of up to 350 mm.
Yes, the BL-1200A is designed to be convenient and fast, making it suitable for both small and large beverage companies.
The BL-1200A is specifically designed to blow mold PET (Polyethylene Terephthalate) bottles.
The BL-1200A provides a faster and more efficient production process compared to manual blowing machines, which helps in increasing productivity.
Regular maintenance includes checking the air compressor, ensuring proper heating functions, and maintaining water flow for cooling to ensure optimal performance.
