The RFID Reader can read RFID cards from a distance of 10mm to 55mm.
It can read ISO14443A and ISO14443B card serial numbers, including second-generation ID cards, FM1208 CPU cards, and Mifare S50/S70 IC cards.
The turnstile supports TCP/IP, UDP, and HTTP communication protocols for flexible network integration.
Yes, it features Wiegand 26/34 output, ensuring seamless compatibility with existing access control systems.
The device supports a flexible power input of 9-18VDC.
The turnstile operates at less than 600mA, making it energy-efficient.
Yes, it is capable of reading multiple symbologies, including 1D barcodes like CODE 128 and 2D barcodes like QR codes.
The compact design measures 105mm (L) x 105mm (W) x 25mm (H).
Yes, it includes voice output features with nearly 150 kinds of customizable voice outputs.
There are two installation sizes available: RD006 at 105mm x 105mm x 25mm and RD007 at 152mm x 85mm x 35mm.
Yes, it has two 250V/5A relay outputs that can control door openers, lights, and valves.
Yes, it includes a 12V DC power input and a single line gate input for easy installation.
It features a white LED light source for clear and precise identification.
The RFID Reader has a full scan angle of 360°.
Yes, it is equipped with extensible wireless options such as WiFi and Bluetooth.
