The primary function of the Micro-Deval Apparatus is to measure the abrasion resistance and wear of aggregates, helping to assess their durability for various applications.
The Micro-Deval Testing Machine complies with EN 1097-1 and EN 13450 standards, ensuring reliable and standardized testing procedures.
The inner diameter of the test cylinder is 200mm ±1mm, and the effective length of the inner cavity can be either 154mm ±1mm or 400mm ±2mm.
The Micro-Deval Apparatus has a motor power of 1kw, which provides sufficient energy for effective testing.
Yes, the Micro-Deval Testing Machine is built with safety features, including a safety cabinet, an automatic stop feature when the cabinet door is opened, and sound-proofing material to reduce noise during operation.
The maximum rotation number setting for the Micro-Deval Apparatus is 0-999999 revolutions.
The Micro-Deval Apparatus is suitable for testing various construction aggregates, including those used in road construction and other civil engineering applications.
The automatic counter allows users to preset the number of revolutions for the test, making it easier to manage and track testing cycles.
The weight of the Micro-Deval Apparatus is 180kg, making it a sturdy and stable unit for testing.
The spindle speed of the Micro-Deval Apparatus can be adjusted from 0 to 200 r/min with stepless speed regulation.
Yes, the Micro-Deval Apparatus supports various sizes of wear steel balls, including diameters of 10mm ±0.5mm, 18mm ±0.5mm, and 30mm ±0.5mm.
The overall dimensions of the Micro-Deval Testing Machine are 1500mm x 600mm x 1200mm.
Laboratories, industries, and researchers involved in materials testing, quality control, and civil engineering would greatly benefit from using the Micro-Deval Apparatus.
Yes, the Micro-Deval Apparatus is ideal for research and development in civil engineering, allowing for thorough evaluation of aggregate performance.
The Micro-Deval Apparatus is equipped with sound-proofing material that minimizes noise levels during testing, making it suitable for laboratory environments.
