MFSC-12000 20000 Laser Generator Sheet Metal Cutting
- Section : Machinery
- Category : Metal & Metallurgy Machinery
- SKU : 1601180635438
Product Description
MAX MFSC-12000
MFSC 12000W single-module continuous fiber laser is a high-power fiber laser with high electro-optical conversion efficiency, compact size, good beam quality, and maintenance-free. It can take into account the high-speed cutting of thin plates and the bright surface cutting of medium and thick plates, greatly improving the perforation, Cutting, welding and other process quality, widely used in laser cutting, laser welding, laser cladding, laser brazing, laser surface heat treatment, etc.
Product Paramenters
| Model | MFSC-12000W | MFSC-800W | MFSC-1000W | MFSC-1200W | MFSC-1300W | MFSC-1500W |
| Optical Properties | ||||||
| Output Power(W) | 12000 | 800 | 1000 | 1200 | 1300 | 1500 |
| Operating Mode | Continuous/ Pulse | |||||
| Power Adjust Range(%) | 10-100 | |||||
| Wavelemgth (nm) | 1080(±10) | |||||
| Spectral Bandwidth 3dB (nm) | 4-7 | |||||
| Laser on time(μs) | 100-150 | |||||
| Laser off time(μs) | 100-150 | |||||
| Modulation Power(KHz) | 5 | |||||
| Indicating Red Light Power(μW) | 200 | |||||
| Output Optical Cable Parameters | ||||||
| Output Mode | LOE | |||||
Fiber Core Diameter (μm) | 50( 100/200 optional) | |||||
| Bending Radius(mm) | 200 | |||||
| Electrical Parameters | ||||||
| Voltage(VAC) | 400 (±40) | |||||
| Rated Power Consumption（KW） | 2.8 | 3.5 | 44 | 5.2 | 6.0 | |
| Other Parameters | ||||||
| Working Temperature (oC) | 10-40 | |||||
| Relative Humidity(%) | 10-80 | |||||
| Cooling Method | Water Cooling | |||||
| Storage Temperature (oC) | -10—60 | |||||
| Size(mm) | 900 x 800 x 1180 | |||||
| Weight(KG) | 428（±5） |
Features
MAX MFSC 12000
* Modular design, stable performance
The internal structure adopts the photoelectric module separation design, and the operating performance is more stable.
*Easy maintenance, reduce downtime
Optical modules, electrical modules, control units, and drive units can be directly replaced, upgraded, and maintained at the client.
*Customized to meet various needs
Users can choose different size of fiber core diameters in accordance with the different process requirements to meet differentiated processing needs.
*Uniform spot energy distribution
Reduce welding spatter, thick plate cutting ability is more stable.
*Multiple applying scenarios
It can be used with laser processing heads, galvanometers, etc. for system integration with robots, machine tools, etc.; Laser fine cutting, precision welding processing, used in 3C, hardware, medical, automotive, aviation and other fields.
Application
- Shipping Timeframes: All orders are processed within 2-5 business days (excluding weekends and holidays). After your order has been processed, the estimated delivery time is before 03 Feb, 2026, depending on customs, Please note that due to high demand, some items may experience longer shipping times, which will be communicated at order confirmation email.
- Order Processing Time: Please allow 2-5 business days for us to process your order before it is shipped . Orders placed after 16:00 on Fridays, or during weekends and public holidays, will begin processing on the next business day. Processing times may be extended during peak seasons or sales events.
- Manufacturing Time: Some products needs manufacturing time, the manufacturing process will take approximately 10-30 business days depending on the product. This timeframe may vary depending on the complexity of the product and current demand. but this will be communicated with you during order confirmation.
- Returns and Exchanges: We offer a 30-day return policy for most items. If you are not completely satisfied with your purchase, you may return it within 30 days of receipt for a refund or exchange. Items must be unused, in their original packaging, and accompanied by proof of purchase. Return shipping costs are the responsibility of the customer, unless the item was damaged or defective upon arrival.
1. What is the maximum output power of the MFSC-12000 laser generator?
The maximum output power of the MFSC-12000 laser generator is 12000W.
2. What types of materials can the MFSC-12000 cut?
The MFSC-12000 can cut thin plates and medium to thick plates, making it suitable for a variety of materials including metal and other sheet materials.
3. How does the MFSC-12000 improve cutting quality?
The MFSC-12000 improves cutting quality by providing high-speed cutting capabilities, excellent beam quality, and a stable performance that reduces welding spatter.
4. Is the MFSC-12000 suitable for welding applications?
Yes, the MFSC-12000 is widely used for laser welding in addition to cutting, cladding, brazing, and surface heat treatment.
5. What is the cooling method used in the MFSC-12000?
The MFSC-12000 uses a water cooling method to maintain optimal operating temperatures.
6. What is the size and weight of the MFSC-12000?
The dimensions of the MFSC-12000 are 900 x 800 x 1180 mm, and it weighs approximately 428 kg.
7. Can the MFSC-12000 be customized for different processing needs?
Yes, the MFSC-12000 can be customized with different fiber core diameters to meet various processing requirements.
8. What is the operating temperature range of the MFSC-12000?
The operating temperature range for the MFSC-12000 is between 10°C to 40°C.
9. What is the power adjustment range for the MFSC-12000?
The power adjustment range for the MFSC-12000 is from 10% to 100%.
10. What industries can benefit from using the MFSC-12000?
The MFSC-12000 is beneficial in various industries including 3C, hardware, medical, automotive, and aviation.
11. How is maintenance handled for the MFSC-12000?
The MFSC-12000 is designed for easy maintenance, allowing for direct replacement and upgrade of optical modules, electrical modules, control units, and drive units.
12. What is the wavelength of the laser produced by the MFSC-12000?
The wavelength of the laser produced by the MFSC-12000 is 1080 nm (±10 nm).
13. What is the spectral bandwidth of the MFSC-12000?
The spectral bandwidth for the MFSC-12000 is 4-7 nm at 3dB.
14. What types of operating modes does the MFSC-12000 support?
The MFSC-12000 supports both continuous and pulse operating modes.
15. What is the rated power consumption of the MFSC-12000?
The rated power consumption of the MFSC-12000 is approximately 45 kW.
