Hydraulic Concrete Crusher
- Section : Machinery
- Category : Engineering & Construction Machinery
- SKU : 60322468130
Product Description
The Excavator Hydraulic Concrete Crusher / Pulverizer is an essential demolition tool designed for breaking and crushing concrete in heavy construction and demolition projects. Available in multiple models, it offers robust and efficient performance with various jaw sizes and force capacities. These crushers are ideal for excavators in different weight ranges, ensuring the ability to handle various types of concrete demolition tasks.
Key Features:
- Heavy-duty Hydraulic Power: Delivers powerful force for quick and efficient concrete crushing, with adjustable force settings.
- Multiple Models for Versatile Applications: Different models (MCP600, MCP800, MCP910, MCP1000) to suit various excavator sizes and job requirements.
- High Cutting Force: Delivers exceptional cutting power at different jaw depths to handle large concrete structures.
- Fast Operational Time: Quick closing and opening times for efficient operation, even at maximum oil flow rates.
- Interchangeable Wear Parts: Available on certain models for extended service life and easier maintenance.
- Customizable Hydraulic Settings: Optional speed valves for increased flexibility in operation.
Technical Specifications:
| Model | MCP600 | MCP800 | MCP910 | MCP1000 |
|---|---|---|---|---|
| Jaw Opening (A) | 800 mm | 1050 mm | 1100 mm | 1350 mm |
| Height (B) | 1800 mm | 2030 mm | 2200 mm | 2800 mm |
| Width (C) | 415 mm | 550 mm | 605 mm | 660 mm |
| Jaw Depth (C) | 730 mm | 810 mm | 900 mm | 1160 mm |
| Excavator Weight | 10-18 t | 18-25 t | 25-35 t | 35-45 t |
| Tool Weight | 1000 kg | 2050 kg | 2850 kg | 3800 kg |
| Cylinder Force | 100 t | 145 t | 157 t | 197 t |
| Force at Upper Tips (F1) | 54 t | 73 t | 99 t | 123 t |
| Force in the Middle (F2) | 79 t | 115 t | 153 t | 195 t |
| Cutting Force (F3) | 155 t | 196 t | 276 t | 348 t |
| Hydraulic Working Pressure | 280-320 bar | 280-320 bar | 280-320 bar | 280-320 bar |
| Oil Flow | 100-180 l/min | 180-220 l/min | 220-280 l/min | 280-320 l/min |
| Rotation Type | No Rotation | No Rotation | No Rotation | No Rotation |
| Time of Closing (at max oil flow) | 3.09 s | 2.28 s | 2.94 s | 3.50 s |
| Time of Opening (at max oil flow) | 1.88 s | 2.26 s | 2.74 s | 3.36 s |
| Cycles per Minute (at max oil flow) | 12.1 cycles/min | 13.2 cycles/min | 10.6 cycles/min | 8.7 cycles/min |
| Hydraulic Ports Size Cylinder | 1" SAE 6000 psi | 1" SAE 6000 psi | 1 1/4" SAE 6000 psi | 1 1/4" SAE 6000 psi |
| Speed Valve | Optional | Yes | Yes | Yes |
| Max Diameter to be Cut | 50 mm | 55 mm | 60 mm | 65 mm |
| Blade Length | 122 mm | 180 mm | 180 mm | 220 mm |
| Interchangeable Wear Parts | No | Yes | Yes | Yes |
| Automatic Grease System | No | No | No | No |
The Excavator Hydraulic Concrete Crusher / Pulverizer is a reliable and durable solution for efficiently processing concrete in construction, demolition, and recycling applications, ensuring maximum productivity and reduced operational downtime.
| MCP600 | MCP800 | MCP910 | MCP1000 | ||
| Jaw opening | A(mm) | 800 | 1050 | 1100 | 1350 |
| Height | B(mm) | 1800 | 2030 | 2200 | 280 |
| Width | C(mm) | 415 | 550 | 605 | 660 |
| Jaw depth | C(mm) | 730 | 810 | 900 | 1160 |
| MCP600 | MCP800 | MCP910 | MCP1000 | ||
| Excavator weight | (t) | 10-18 | 18-25 | 25-35 | 35-45 |
| Tool weight* | (kg) | 1000 | 2050 | 2850 | 3800 |
| Cylinder force | (t) | 100 | 145 | 157 | 197 |
| Force at upper tips F1 (front teeth) | (t) | 54 | 73 | 99 | 123 |
| Force in the middle F2 (middle of blade) | (t) | 79 | 115 | 153 | 195 |
| Cutting force F3 | (t) | 155 | 196 | 276 | 348 |
| Hydraulic working pressure | (bar) | 280-320 | 280-320 | 280-320 | 280-320 |
| Oil flow | (l/min) | 100-180 | 180-220 | 220-280 | 280-320 |
| Rotation type | NO ROT. | NO ROT. | NO ROT. | NO ROT. | |
| Time of closing at max oil flow | (s.) | 3,09 | 2,28 | 2,94 | 3,50 |
| Time of opening at max oil flow | (s.) | 1,88 | 2,26 | 2,74 | 3,36 |
| N°of cycles per minute at max oil flow | (cycles/min) | 12,1 | 13,2 | 10,6 | 8,7 |
| Hyd. ports size cylinder | / | 1’’ SAE 6000 p.s.i. | 1’’ SAE 6000 p.s.i. | 1’’1/4 SAE 6000 p.s.i. | 1’’1/4 SAE 6000 p.s.i. |
| Speed valve | / | Optional | Yes | Yes | Yes |
| Max diameter to be cut** | (mm) | 50 | 55 | 60 | 65 |
| Blade length | (mm) | 122 | 180 | 180 | 220 |
| Interchangeable wear parts | / | NO | Yes | Yes | Yes |
| Automatic grease system | / | NO | NO | NO | NO |
- Shipping Timeframes: All orders are processed within 2-5 business days (excluding weekends and holidays). After your order has been processed, the estimated delivery time is before 03 Feb, 2026, depending on customs, Please note that due to high demand, some items may experience longer shipping times, which will be communicated at order confirmation email.
- Order Processing Time: Please allow 2-5 business days for us to process your order before it is shipped . Orders placed after 16:00 on Fridays, or during weekends and public holidays, will begin processing on the next business day. Processing times may be extended during peak seasons or sales events.
- Manufacturing Time: Some products needs manufacturing time, the manufacturing process will take approximately 10-30 business days depending on the product. This timeframe may vary depending on the complexity of the product and current demand. but this will be communicated with you during order confirmation.
- Returns and Exchanges: We offer a 30-day return policy for most items. If you are not completely satisfied with your purchase, you may return it within 30 days of receipt for a refund or exchange. Items must be unused, in their original packaging, and accompanied by proof of purchase. Return shipping costs are the responsibility of the customer, unless the item was damaged or defective upon arrival.
1. What is a Hydraulic Concrete Crusher?
A Hydraulic Concrete Crusher is a demolition tool designed for breaking and crushing concrete in heavy construction and demolition projects using hydraulic power.
2. What models of Hydraulic Concrete Crushers are available?
The available models include MCP600, MCP800, MCP910, and MCP1000, each designed to suit different excavator sizes and job requirements.
3. What is the weight range of excavators suitable for these crushers?
The crushers are designed for excavators weighing between 10 to 45 tons, depending on the model.
4. What is the cutting force of the Hydraulic Concrete Crusher?
The cutting force varies by model, ranging from 155 tons for the MCP600 to 348 tons for the MCP1000.
5. How fast can the crusher operate?
The operational times vary by model, with the time to close ranging from 2.28 seconds to 3.50 seconds at maximum oil flow.
6. Are there interchangeable wear parts available?
Interchangeable wear parts are available for the MCP800, MCP910, and MCP1000 models, allowing for extended service life and easier maintenance.
7. What is the maximum diameter that can be cut with the crushers?
The maximum diameter to be cut varies by model, with a maximum of 65 mm for the MCP1000.
8. What hydraulic working pressure do these crushers operate at?
All models operate at a hydraulic working pressure of 280-320 bar.
9. Can the hydraulic settings be customized?
Yes, optional speed valves are available for increased flexibility in operation.
10. What is the oil flow requirement for each model?
Oil flow requirements vary by model: MCP600 (100-180 l/min), MCP800 (180-220 l/min), MCP910 (220-280 l/min), and MCP1000 (280-320 l/min).
11. What is the weight of the Hydraulic Concrete Crushers?
The tool weight varies by model, from 1000 kg for the MCP600 to 3800 kg for the MCP1000.
12. Is there an automatic grease system in the crushers?
No, the Hydraulic Concrete Crushers do not come with an automatic grease system.
13. What type of rotation is used in these crushers?
All models of the Hydraulic Concrete Crushers operate without rotation.
14. What is the jaw opening size of the MCP1000 model?
The jaw opening size of the MCP1000 model is 1350 mm.
15. How many cycles per minute can these crushers achieve?
The number of cycles per minute ranges from 8.7 cycles/min for the MCP1000 to 13.2 cycles/min for the MCP800 at maximum oil flow.
