Digital Ultrasonic Flaw Detector Ndt Metal Ultrasonic Flaw Tester
- Section : Consumer Electronics
- Category : Testing Equipment
- SKU : 1601025016078
Digital Ultrasonic Flaw Detector Ndt Metal Ultrasonic Flaw Tester
The Digital Ultrasonic Flaw Detector Ndt Metal Ultrasonic Flaw Tester is a cutting-edge tool designed for inspecting metal materials. It helps find hidden flaws and ensures the quality and safety of metal structures. This device is easy to use and delivers accurate results, making it essential for various industries.
Specifications
| Attribute | Details |
|---|---|
| Dimensions | 263*170*61 (mm) |
| Discrimination | >40dB(5P14) |
| Dynamic Range | ≥36dB |
| Electrical Noise Level | ≤8% |
| Examination Range | (0-9999) mm |
| Horizontal Linearity Error | ≤0.1% |
| Model Number | IWIN-U600 |
| Single Gross Weight | 7.000 kg |
| Single Package Size | 43X19X14 cm |
| Sound Speed Range | (1000~15000) m/s |
| Vertical Linearity Error | ≤2.5% |
| Working Frequency | (0.2~20) MHz |
| Power Electronic | ≤1h2010 |
Key Features
- High accuracy in detecting metal flaws.
- Lightweight and portable design.
- Wide examination range up to 9999 mm.
- Easy-to-read display for quick results.
- Robust construction for durability.
Applications
- Quality control in manufacturing.
- Inspection of welds and joints.
- Maintenance checks on machinery.
- Structural evaluation in construction.
- Research and development in material science.
| U600 Series Ultrasonic Flaw Detector | ||||
| Standard number | TSG R0004-2009 EN12668-1:2000 | |||
| Product Description | IWIN-U600 | IWIN-610 | IWIN-620 | IWIN-630 |
| Working principle | Ultrasonic | Ultrasonic | Ultrasonic | Ultrasonic |
| Working frequency | (0.2~20)MHz | (0.5~20)MHz | (0.5~20)MHz | (0.5~20)MHz |
| Pulse Width | Square wave width 30~1000ns adjustable, step 0.1ns | Square wave width 30~1000ns adjustable, step 0.1ns | Square wave width 30~1000ns adjustable, step 0.1ns | Square wave width 30~1000ns adjustable, step 0.1ns |
| Detection range | 0~14000 (Steel longitudinal wave)mm | 0~14000 (Steel longitudinal wave)mm | 0~14000 (Steel longitudinal wave)mm | 0~14000 (Steel longitudinal wave)mm |
| Pulse shift | -45~1000(steel longitudinal wave)mm | -45~1000(steel longitudinal wave)mm | -45~1000(steel longitudinal wave)mm | -45~1000(steel longitudinal wave)mm |
| Material sound velocity | 300~15000m/s | 300~15000m/s | 300~15000m/s | 300~15000m/s |
| Detection method | Negative wave, positive wave, two-way wave, filter, RF wave | Negative wave, positive wave, two-way wave, filter, RF wave | Negative wave, positive wave, two-way wave, filter, RF wave | Negative wave, positive wave, two-way wave, filter, RF wave |
| Gain adjustment | 0~110dB: 0.1/1/2/6 step adjustment | 0~110dB: 0.1/1/2/6 step adjustment | 0~110dB: 0.1/1/2/6 step adjustment | 0~110dB: 0.1/1/2/6 step adjustment |
| Thickness measurement function | non | non | Normal mode 0.75-300mm, penetration coating 2-150mm | Normal mode 0.75-300mm, penetration coating 2-150mm |
| WIFI/HDMI/digital filtering wave | non | non | non | Mobile phone connection/HD projection/digital filtering |
| Sluice gate | Incoming gate, loss gate; single gate reading, double gate reading | Incoming gate, loss gate; single gate reading, double gate reading | Incoming gate, loss gate; single gate reading, double gate reading | Incoming gate, loss gate; single gate reading, double gate reading |
| DAC、AVG Function | DAC curve、AVG curve | DAC curve、AVG curve | DAC curve、AVG curve | DAC curve、AVG curve |
| Attenuator error | Every 12dB+-1dB | Every 12dB+-1dB | Every 12dB+-1dB | Every 12dB+-1dB |
| Vertical linearity error | ≤3% | ≤3% | ≤3% | ≤3% |
| Horizontal linearity error | ≤0.5% | ≤0.5% | ≤0.5% | ≤0.5% |
| Dynamic Range | ≥30dB | ≥30dB | ≥30dB | ≥30dB |
| Sensitivity margin | ≥65dB (2.5Z20N Probe) | ≥65dB (2.5Z20N Probe) | ≥65dB (2.5Z20N Probe) | ≥65dB (2.5Z20N Probe) |
| Far zone resolution | ≥26dB | ≥26dB | ≥26dB | ≥26dB |
| Electrical noise level | ≤10(1~4MHz)% | ≤10(1~4MHz)% | ≤10(1~4MHz)% | ≤10(1~4MHz)% |
| Equivalent input noise | ＜80x10-9V/√Hz | ＜80x10-9V/√Hz | ＜80x10-9V/√Hz | ＜80x10-9V/√Hz |
| Pulse repetition frequency | 20~1000Hz，Stepping 25V | 20~1000Hz，Stepping 25V | 20~1000Hz，Stepping 25V | 20~1000Hz，Stepping 25V |
| Pulse voltage | 25~400V can adjust,step 25V | 25~400V can adjust,step 25V | 25~400V can adjust,step 25V | 25~400V can adjust,step 25V |
| Thin plate resolution | ≤3(5C10N Probe)mm | ≤3(5C10N Probe)mm | ≤3(5C10N Probe)mm | ≤3(5C10N Probe)mm |
| AWS D1.1/D1.5 | The AWS D1.1/D1.5 of the American Welding Association (AWS) calculates the weld level of steel structures and bridges | Support | Support | Support |
| Working voltage | 12V (Battery,DC) | 12V (Battery,DC) | 12V (Battery,DC) | 12V (Battery,DC) |
| Appearance size | 180x130x40mm (Height*Width*Depth) | 180x130x40mm (Height*Width*Depth) | 180x130x40mm (Height*Width*Depth) | 180x130x40mm (Height*Width*Depth) |
| Storage | Storage card | Storage card | Storage card | Storage card |
| Probe damping | 100Ω, 200Ω, 400Ω optional | |||
| Real-time sampling of hardware | High resolution 10-bit AD converter with sampling speed of 160MHz and high waveform fidelity | |||
| Detection method | Positive half wave, negative half wave, full wave, radio frequency detection | |||
| Filter band | (0.2~20)MHz, fully automatic matching according to probe frequency, no need to set manually | |||
| Communication Interface | USB2.0 high speed communication transmission interface | |||
| Ambient temperature and humidity | Temperature: (-10~50) °C Humidity: (20~95)%RH | |||
