50L rotary evaporator and supporting equipment with fast delivery
- Section : Machinery
- Category : Industrial Machinery
- SKU : 60680071694
RE-5002 Industrial Rotary Evaporator 50L
The Rotary Evaporator is a high-efficiency distillation and extraction device, primarily used in processes such as concentration, refinement, separation, crystallization, and drying. It operates under normal or negative pressure with constant heating, effectively separating solvents based on their boiling points. Widely applied in biochemical and fine chemical industries, it ensures precision and reliability for laboratory and industrial purposes.
Key Features:
Frequency Conversion Rotation Speed Regulation:
Achieve precise control over the rotation speed for optimal evaporation efficiency.
PTFE Rotary Seal Assembly:
Provides excellent sealing performance, ensuring a stable vacuum environment and contamination-free operation.
Water or Oil Heating Option:
Select the appropriate heating medium based on required temperatures for different applications.
Liftable Heating Bath:
Equipped with an intelligent temperature controller for precise and consistent heating. Manual or electric lift options are available.
Flexible Condenser Design:
Offers vertical or diagonal condenser configurations for versatile usage.
Specifications of Rotary Evaporator 50L:
| Specification | RE-1002 | RE-2002 | RE-3002 | RE-5002 |
|---|---|---|---|---|
| Rotary Flask | 10L | 20L | 30L | 50L |
| Receiving Flask | 5L | 10L | 20L | 20L |
| Evaporating Speed (H₂O) | >3L/h | >5L/h | 7L/h | 9L/h |
| Discharge | PTFE | PTFE | PTFE | PTFE |
| Motor Power | 180W | 180W | 250W | 250W |
| Rotation Speed | 10–120rpm | 10–120rpm | 10–90rpm | 10–90rpm |
| Heating Power | 3kW | 3kW | 6kW | 6kW |
| Bath Temp Range | Water: RT–90°C / Oil: RT–180°C | |||
| Reachable Vacuum Rate | <133Pa (1 Torr) | |||
| Voltage | 220V–240V, 50Hz | |||
| Dimensions (Approx.) | Vary based on model |
Detailed Images:
- Controller: Digital display for precise rotation speed control with optional explosion-proof design.
- Sealing: High-quality PTFE sealing for stable vacuum performance and material safety.
- Motor: Durable 180W/250W AC motor ensures long service life with reliable operation.
- Bath: Manual lift heating bath with digital temperature display for easy handling.
Supporting Equipment:
Vacuum Controller:
For precise vacuum regulation based on process requirements.
Low-Temperature Recirculating Chiller:
Efficiently cools the condenser to enhance collection performance.
Circulating Water Vacuum Pump:
Maintains stable vacuum levels for smooth operation.
- Shipping Timeframes: All orders are processed within 2-5 business days (excluding weekends and holidays). After your order has been processed, the estimated delivery time is before 03 Feb, 2026, depending on customs, Please note that due to high demand, some items may experience longer shipping times, which will be communicated at order confirmation email.
- Order Processing Time: Please allow 2-5 business days for us to process your order before it is shipped . Orders placed after 16:00 on Fridays, or during weekends and public holidays, will begin processing on the next business day. Processing times may be extended during peak seasons or sales events.
- Manufacturing Time: Some products needs manufacturing time, the manufacturing process will take approximately 10-30 business days depending on the product. This timeframe may vary depending on the complexity of the product and current demand. but this will be communicated with you during order confirmation.
- Returns and Exchanges: We offer a 30-day return policy for most items. If you are not completely satisfied with your purchase, you may return it within 30 days of receipt for a refund or exchange. Items must be unused, in their original packaging, and accompanied by proof of purchase. Return shipping costs are the responsibility of the customer, unless the item was damaged or defective upon arrival.
1. What is the primary use of the 50L rotary evaporator?
The 50L rotary evaporator is primarily used for distillation and extraction processes, including concentration, refinement, separation, crystallization, and drying in biochemical and fine chemical industries.
2. How does the rotary evaporator separate solvents?
It operates under normal or negative pressure with constant heating, effectively separating solvents based on their boiling points.
3. What is the evaporating speed of the RE-5002 model?
The RE-5002 model has an evaporating speed of over 9L/h when using water as the solvent.
4. What type of motor does the RE-5002 rotary evaporator use?
The RE-5002 is equipped with a durable 250W AC motor that ensures long service life and reliable operation.
5. What is the temperature range of the heating bath?
The heating bath can reach temperatures from RT to 90°C when using water, and from RT to 180°C when using oil.
6. Is the rotary evaporator compatible with different heating mediums?
Yes, the rotary evaporator allows for the selection of either water or oil as the heating medium based on the temperature requirements of different applications.
7. What features ensure stable vacuum performance?
The PTFE rotary seal assembly provides excellent sealing performance, ensuring a stable vacuum environment and contamination-free operation.
8. Can the heating bath be adjusted manually?
Yes, the rotary evaporator is equipped with a liftable heating bath that offers both manual and electric lift options for easy adjustment.
9. What is the voltage requirement for the RE-5002 model?
The RE-5002 rotary evaporator operates on a voltage of 220V–240V at a frequency of 50Hz.
10. What are the dimensions of the RE-5002 rotary evaporator?
The dimensions of the RE-5002 vary based on the model specifications, so it's best to refer to the product details for precise measurements.
11. Does the rotary evaporator come with supporting equipment?
Yes, the rotary evaporator can be paired with supporting equipment such as a vacuum controller, low-temperature recirculating chiller, and circulating water vacuum pump.
12. What is the function of the vacuum controller?
The vacuum controller allows for precise vacuum regulation based on the specific requirements of the distillation or extraction process.
13. What is the significance of frequency conversion rotation speed regulation?
Frequency conversion rotation speed regulation allows for precise control over the rotation speed for optimal evaporation efficiency, which can enhance the overall performance of the rotary evaporator.
14. How is the digital controller beneficial?
The digital controller provides a precise display for rotation speed control and can include optional explosion-proof features for added safety.
15. What industries commonly use the 50L rotary evaporator?
The 50L rotary evaporator is widely applied in the biochemical and fine chemical industries, ensuring precision and reliability for both laboratory and industrial purposes.
