21m Self-propelled Boom Movable Boom Lift
- Section : Machinery
- Category : Engineering & Construction Machinery
- SKU : 1600691975376
21m Self-propelled Boom Movable Boom Lift
The 21m Self-propelled Boom Movable Boom Lift is designed to offer high-performance lifting with ease and precision. Fully automatic and equipped with a crank boom, this lift is perfect for a wide range of construction, maintenance, and industrial applications, providing both power and flexibility.
Key Features:
- Impressive Lifting Capacity: With a maximum working height of 21 meters, this lift provides excellent reach for tasks that require extended vertical access, making it ideal for construction, cleaning, and maintenance work at height.
- Fully Automatic Operation: The fully automatic system ensures ease of use, reducing operator workload while delivering smooth, controlled movements.
- Powerful Engine & Motor: Equipped with a powerful engine, motor, and pump, this boom lift is designed to handle heavy-duty lifting tasks, even in tough environments.
- Easy Maintenance: With its simple design and robust components, this boom lift ensures easy maintenance, reducing downtime and keeping operations running smoothly.
- High Mobility: The self-propelled design allows for easy movement, making it convenient to position the lift for different tasks. It offers a maximum speed of 6.1 km/h, allowing for quick adjustments.
- Impressive Climb Capability: Capable of climbing inclines of up to 45°, this lift can navigate challenging terrains and still perform effectively.
- Excellent Turning Radius: Featuring a compact inner turning radius of 2780 mm and an outer turning radius of 5490 mm, this lift provides excellent maneuverability in tight spaces.
- 360° Rotary Turntable: The turntable allows for a 400° discontinuity rotary angle, providing flexibility in positioning the platform for tasks at various angles.
- Platform Swing: The platform can swing ±90°, providing a wide range of movement to reach difficult areas.
- Operational Safety: Designed with a maximum working wind speed of 12.5 m/s, this lift is built to operate safely even in moderate wind conditions.
| Basic | |||
| Brand | Jiubang | Drive | electric |
| Dimensions(L x W x H) | 8720 x 2490 x 2520(mm) | Gross Vehicle Weight | 9200 Kg |
| Max. speed | 6.1 Km/h | Max. Climb Capability | 45° |
| Wheelbase | 2520 mm | Swing height of axle | 200 mm |
| Inner turning radius | 2780 mm | Outside turning radius | 5490 mm |
| Tyre | 33 x 12/D610 foam filled tyres | ||
| Aerial work platform | |||
| Working platform dimensions | 1830 x 760 x 1200 mm | Rated load | 250 Kg |
| Max. working height | 21 m | Max. horizontal height | 19.45 m |
| Max. horizontal extension | 11.45 m | Max. crossing height | 8.25 m |
| Working boom | Polygonal Folding arm | Tail pendulum | 0.6 m |
| Rotary angle of turntable | 400° discontinuity | Swing angle of platform | ±90° |
| Max. working angle | 3/5° | Max. working wind speed | 12.5 m/s |
| Mini. ground clearance | 330mm | ||
| Operation mode | Remote / electric | ||
| Power | |||
| Battery | 8 x 6v/420Ah | Charger | 48v/35A |
| Drive motor | AC32v/3.3kw | Lifting motor | AC32v/10kw |
| Auxiliary power | Auxiliary power | ||
| Hydraulic oil tank | 75 L | ||
The 21m Self-propelled Boom Movable Boom Lift is a versatile, durable, and highly efficient lift designed for both indoor and outdoor use. Its high mobility, powerful performance, and easy maintenance make it the perfect choice for heavy-duty lifting and working at height.
Product Info Gallery
Jiubang self-propelled aerial work platform adopts a fully hydraulic self-propelled special chassis, which is designed with electromechanical and hydraulic integration. It does not need to operate the folding arm, and can be quickly lifted and lowered to improve work efficiency. The accurate and funny walking AC drive system and the boarding action AC drive system make the vehicle more powerful and more stable, and are widely used in various aerial work fields.
SHANGHAI BAOSTEEL WORKING BOOM
High strength, stronger bearing capacity
GOOD OPERATION STABILITY
Optimize the overall layout and load distribution to reduce the center of gravity shift
SKETCH MAP OF
WORKING SITE
The maximum working height is 21m, and the platform load is 250Kgm, providing customers with a higher working intensity and stronger carrying capacity of the aerial work platform.
Folding boom
Telescopic boom
ROTARY DEVICE
The working platform and rotary device can rotate
The chassis can rotate 360 degrees
Hydraulic slewing device of working platform
CONTROL SYSTEM
Different operation modes in different construction environments
The bottom controls the computer, and the graph shows the length, height, angle, etc. of the working arm
Working platform console, which can precisely control walking, boarding, etc
TRAVELING SYSTEM
Different operation modes in different construction environments
Four steerable travel drive motors
Non marking solid tire, stable driving and strong load
HYDRAULIC CYLINDER LOCK
Equip balance valve or hydraulic lock to ensure construction safety
MANNED WORK PLATFORM
Multiple safety schemes to ensure personnel and construction safety
MORE PRODUCT DETAILS
Details determine product quality
PRODUCT PHOTOGRAPH
More real product photos
- Shipping Timeframes: All orders are processed within 2-5 business days (excluding weekends and holidays). After your order has been processed, the estimated delivery time is before 03 Feb, 2026, depending on customs, Please note that due to high demand, some items may experience longer shipping times, which will be communicated at order confirmation email.
- Order Processing Time: Please allow 2-5 business days for us to process your order before it is shipped . Orders placed after 16:00 on Fridays, or during weekends and public holidays, will begin processing on the next business day. Processing times may be extended during peak seasons or sales events.
- Manufacturing Time: Some products needs manufacturing time, the manufacturing process will take approximately 10-30 business days depending on the product. This timeframe may vary depending on the complexity of the product and current demand. but this will be communicated with you during order confirmation.
- Returns and Exchanges: We offer a 30-day return policy for most items. If you are not completely satisfied with your purchase, you may return it within 30 days of receipt for a refund or exchange. Items must be unused, in their original packaging, and accompanied by proof of purchase. Return shipping costs are the responsibility of the customer, unless the item was damaged or defective upon arrival.
1. What is the maximum working height of the 21m Self-propelled Boom Movable Boom Lift?
The maximum working height of the lift is 21 meters, making it suitable for various tasks that require extended vertical access.
2. What is the rated load capacity of this boom lift?
The rated load capacity of the boom lift is 250 kg, which allows for substantial lifting tasks.
3. How does the fully automatic operation work?
The fully automatic system simplifies operation, allowing for smooth and controlled movements without extensive manual effort from the operator.
4. What type of engine powers the boom lift?
The boom lift is equipped with a powerful engine and motor designed to handle heavy-duty lifting tasks, even in challenging environments.
5. What are the dimensions of the working platform?
The working platform dimensions are 1830 mm in length, 760 mm in width, and 1200 mm in height.
6. Is the boom lift suitable for outdoor use?
Yes, the 21m Self-propelled Boom Movable Boom Lift is designed for both indoor and outdoor applications, providing high mobility and performance.
7. How fast can the boom lift move?
The maximum speed of the boom lift is 6.1 km/h, allowing for quick adjustments between tasks.
8. What is the maximum climb capability of this lift?
The lift can climb inclines of up to 45°, making it suitable for navigating challenging terrains.
9. What safety features are included in this boom lift?
The boom lift includes multiple safety schemes, such as a hydraulic lock and balance valve, to ensure safe operation during lifting tasks.
10. Can the platform swing to reach difficult areas?
Yes, the platform can swing ±90°, providing a wide range of movement for accessing hard-to-reach areas.
11. What is the operational wind speed limit for this lift?
The boom lift is designed to operate safely in wind speeds of up to 12.5 m/s.
12. How easy is it to maintain this boom lift?
The lift features a simple design and robust components, ensuring easy maintenance and reducing downtime.
13. What type of tyres does the lift use?
The boom lift is equipped with 33 x 12/D610 foam-filled tyres that provide stability and durability.
14. What is the turning radius of the boom lift?
The lift has a compact inner turning radius of 2780 mm and an outer turning radius of 5490 mm, allowing for excellent maneuverability in tight spaces.
15. What power source does the boom lift use?
The boom lift is powered by a battery system consisting of 8 x 6V/420Ah batteries and has an auxiliary power feature.
