100m depth hard rocks hydraulic deep water well drilling rigs 20m depth hydraulic borehole drilling machine rig
- Section : Machinery
- Category : Mining Machinery
- SKU : 1700010529428
Product Overview
full hydraulic drilling rig Water Well geotechnical drilling machine / bore well machine / mine drilling rig / water well drilling machine / water well drill rig / 200m Borehole Mini Water Well Drilling Rig Coring Drill Rig
Application:
1. Well drilling
2. Coal Mining
3. Oil Mining
4. Rock Drilling
Core Drilling Rig Introduction:
HZ-130/180/200YY series drilling rigs can increase the rig displacement slides, which can quickly change the drilling tools to improve work efficiency and reduce labor intensity.
200m Borehole Mini Water Well Drilling Rig Coring Drill Rig Advantage:
* Engine:Feed by hydraulic cylinder,the drilling efficiency is higher and it can save labor.
* Drill rod:53x59 drilling rod adopted,high rigidity and strong delivery torque.
* Spindle:Vertical spindle are fixed by four groups of bearing to ensure that the rotary machine is rigid enough for gravel layer and other complex geoloical conditions.
* Mud pump:Equip mud pump with flow 160L/min,save cost and also make the structure compact.
* Concentrated handle, small footprint,light weight, strong decomposition, easy to move.
Core Drilling Rig Features:
1. It has automatic hydraulic feeding mechanism to improve drilling efficiency and reduce labor intensity.
2. The ball card clamping mechanism is used instead of the chuck, and the non-stop bar can be implemented, which is convenient to operate, safe and reliable.
3. The hoist is equipped with a cage to form a double-sided support star wheel structure, which can withstand strong impact
4. Four sets of bearing positioning of the vertical axle box ensure that the gyrator has sufficient rigidity to deal with
complicated geological conditions such as gravel layer and pebble layer.
5. This machine adopts the national patented taper clutch, which has the characteristics of large transmission torque, convenient operation and maintenance-free.
PRODUCT SPECIFICATIONS
| Technical Parameters of Core Drilling Rig | ||||
| Whole machine technical parameters | Model | HZ-130Y/130YY | HZ-180Y/180YY | HZ-200Y/200YY |
| Drilling depth(m) | 130 | 180 | 200 | |
| Open hole diameter(mm) | 220 | 220 | 325 | |
| End hole diameter(mm) | 75 | 75 | 75 | |
| Drill rod diameter(mm) | 42-60 | 42-60 | 42-60 | |
| Drill angle(°) | 90-75 | 90-75 | 90-75 | |
| Matching power(kw) | 13.2 | 13.2 | 14.7 | |
| Weight without power(kg) | 600/740 | 620/750 | 880/970 | |
| Dimension(m) | 2.4*0.8*1.4 | 2.4*0.8*1.3 | 2.7*0.9*1.5 | |
| Spindle | Speed(r/min) | 142/285/570 | 130/300/480/ 730/830/1045 | 64/128/287/557 |
| Stroke(mm) | 450 | 450 | 450 | |
| Winch | Max pull force(kg) | 2000 | 2100 | 2500 |
| Pull speed(m/s) | 0.41-1.64 | 0.35-2.23 | 0.12-0.95 | |
| Rope diameter(mm) | φ9.3 | φ9.3 | φ12.5 | |
| Roll capacity(m) | 27 | 27 | 35 | |
| Drill Mast | Rated load(ton) | 18 | 18 | 18 |
| Height(m) | 6.5 | 6.5 | 6.5 | |
| Mud pump | Flow(L/min) | 95 | 95 | 145 |
| Max. pressure (Mpa) | 1.2 | 1.2 | 2 | |
| Times/min | 93 | 93 | 93 | |
| Inlet hose diameter(mm) | 51 | 51 | 51 | |
| Outlet hose diameter(mm) | 32 | 32 | 38 |
- Shipping Timeframes: All orders are processed within 2-5 business days (excluding weekends and holidays). After your order has been processed, the estimated delivery time is before 03 Feb, 2026, depending on customs, Please note that due to high demand, some items may experience longer shipping times, which will be communicated at order confirmation email.
- Order Processing Time: Please allow 2-5 business days for us to process your order before it is shipped . Orders placed after 16:00 on Fridays, or during weekends and public holidays, will begin processing on the next business day. Processing times may be extended during peak seasons or sales events.
- Manufacturing Time: Some products needs manufacturing time, the manufacturing process will take approximately 10-30 business days depending on the product. This timeframe may vary depending on the complexity of the product and current demand. but this will be communicated with you during order confirmation.
- Returns and Exchanges: We offer a 30-day return policy for most items. If you are not completely satisfied with your purchase, you may return it within 30 days of receipt for a refund or exchange. Items must be unused, in their original packaging, and accompanied by proof of purchase. Return shipping costs are the responsibility of the customer, unless the item was damaged or defective upon arrival.
1. What is the maximum drilling depth of this hydraulic deep water well drilling rig?
The maximum drilling depth of this rig is 200 meters.
2. What types of drilling applications can this machine be used for?
This machine can be used for well drilling, coal mining, oil mining, and rock drilling.
3. How does the hydraulic feeding mechanism improve efficiency?
The automatic hydraulic feeding mechanism enhances drilling efficiency by reducing labor intensity and allowing for faster drilling operations.
4. What is the weight of the HZ-200Y model without power?
The weight of the HZ-200Y model without power is 970 kg.
5. What is the open hole diameter for the HZ-130Y model?
The open hole diameter for the HZ-130Y model is 220 mm.
6. Can this drilling rig operate in complex geological conditions?
Yes, the rig is designed to handle complicated geological conditions, such as gravel and pebble layers, thanks to its robust spindle and bearing positioning.
7. What is the role of the mud pump in this drilling rig?
The mud pump, equipped with a flow rate of 160 L/min, helps in reducing costs and maintaining a compact structure while facilitating the drilling process.
8. How is the drill rod's rigidity ensured?
The drill rod features a diameter of 53 x 59 mm, which provides high rigidity and strong delivery torque for effective drilling.
9. What are the dimensions of the HZ-180Y model?
The dimensions of the HZ-180Y model are 2.4 m x 0.8 m x 1.3 m.
10. What is the purpose of the patented taper clutch in this rig?
The patented taper clutch allows for large transmission torque and easy operation, making it maintenance-free.
11. How can I transport this drilling rig?
The rig is designed to be lightweight and has a strong decomposition feature, making it easy to move and transport.
12. What is the maximum pull force of the winch?
The maximum pull force of the winch varies by model: 2000 kg for HZ-130Y, 2100 kg for HZ-180Y, and 2500 kg for HZ-200Y.
13. What is the inlet hose diameter for the mud pump?
The inlet hose diameter for the mud pump is 51 mm across all models.
14. What is the drill angle range for these rigs?
The drill angle range for all models is between 90° to 75°.
15. What is the maximum pressure of the mud pump?
The maximum pressure of the mud pump is 1.2 MPa for all models.
